PRODUCT DESCRIPTION
Specifications
Product family
Range
Range size
36"
Range fuel
Gas
N. of ovens
1
Main oven
Gas with grill
EAN code
8017709265236
Color
White
Aesthetics
Portofino
Design
Flush mounted
Material
Painted metal
Door
With frame
Control panel finish
Metal enameled
Cooktop color
Stainless steel
Handle
Portofino
Controls color
Stainless steel
Upstand
Yes
Display
Touch
Grates
Cast Iron
Door glass type
Gray
Handle color
Colored
Control knobs
Portofino
No. of controls
8
Feet
Stainless steel
Plinth
Black
Storage compartment
Push-pull
Control setting type
Control knobs
Timer
Yes
End-of-cooking alarm
Yes
Minimum Temperature
120 (degree)F
Maximum temperature
500 (degree)F
Cooking zones
5
Zone 1 - Type
Gas - Dual ultra-rapid
Zone 2 - Type
Gas - AUX
Zone 3 - Type
Gas - Rapid
Zone 4 - Type
Gas - Rapid
Zone 5 - Type
Gas - Semi-rapid
Zone 1 - Power
5860 W
Zone 2 - Power
1310 W
Zone 3 - Power
3080 W
Zone 4 - Power
3510 W
Zone 5 - Power
2340 W
Burners type
Standard
Burner caps
Enameled matte black
Automatic gas ignition
Yes
Gas safety valves
Yes
Zone 1 - Position
Left
Zone 2 - Position
Rear-center
Zone 3 - Position
Front-center
Zone 4 - Position
Rear-right
Zone 5 - Position
Front-right
Volume
0.16 cu. ft.
Cavity material
EverClean enamel
No. of shelves
5
Shelves type
Metal racks
No. of lights
2
Light type
Halogen
Light Power
40 W
Fan number
3
Time setting
Start and end
Door opening
Drop-down
Removable door
Yes
Full-glass inner door
Yes
Removable inner door
Yes
Total no. of door glasses
3
No.of thermo-reflective door glasses
2
Safety thermostat
Yes
Cooling system
Tangential
Grill type
Gas
Soft Close system
Yes
Temperature control
Electro-mechanical
Electrical connection rating
200 W
Current
2 A
Circuit breaker
15 A
Voltage
120 V
Voltage (V)
120 V
Frequency
60 Hz
Power cord length
47 1/4 "
Type of electric cable installed
Yes, Single phase
Plug
NEMA 5-15P
Gas Type
G20/G25 - 20/25 mbar
Dimensions
915x912x635 mm
Width
35 7/8 "
Height
36 1/16 "
Depth
25 1/16 "
Packaged dimensions
976X950X670 mm
Gross weight
265 lbs
Net weight
234 lbs
Packaged width
37 3/8 "
Packaged depth
26 3/8 "
Packaged height
38 7/16 "
Maximum stackability
4
Packaging
Cardboard box
Packaging composition - Paper
11 lbs
Packaging composition - Polystyrene
13 lbs
Packaging composition - Wood
7 lbs
Packaging composition - Plastics
1 lbs
Other gas nozzles included
G30 LPG liquid gas
Cast iron wok support
1
TOP Oven grid with back stop
2
Grill mesh
1
0.8"-deep tray
1
Telescopic Guide rails, total Extraction
1
GTIN
08017709265236
EAN
8017709265236
Product family: Range
Aesthetics: Portofino
Color: White
Main oven: Gas with grill
Product family
Range
Range size
36"
Range type
Full gas
Cooktop
Gas
N. of ovens
1
Main oven
Gas with grill
EAN code
8017709265236
Installation positioning of the appliance
Free-standing, Class 1, Built-in, Class 2-1 norm UNI EN 30-1-1
Cast iron wok support
1
TOP Oven grid with back stop
2
Grill mesh
1
0.8"-deep tray
1
Telescopic Guide rails, total Extraction
1
