PRODUCT DESCRIPTION
Specifications
Product family
Range
Range size
30"
Range fuel
Dual-fuel
N. of ovens
1
Main oven
Thermo-ventilated
EAN code
8017709260699
Color
Anthracite
Aesthetics
Portofino
Design
Flush mounted
Material
Painted metal
Door
With frame
Control panel finish
Metal enameled
Cooktop color
Stainless steel
Handle
Portofino
Controls color
Stainless steel
Upstand
Yes
Display
Touch
Grates
Cast Iron
Door glass type
Gray
Handle color
Colored
Control knobs
Portofino
No. of controls
7
Feet
Stainless steel
Plinth
Black
Storage compartment
Storage drawer
Control setting type
Control knobs
Timer
Yes
End-of-cooking alarm
Yes
Minimum Temperature
120 (degree)F
Maximum temperature
500 (degree)F
Cooking zones
4
Zone 1 - Type
Gas - Dual ultra-rapid
Zone 2 - Type
Gas - Semi-rapid
Zone 3 - Type
AUX
Zone 4 - Type
Gas - Ultra-rapid
Zone 1 - Power
5860 W
Zone 2 - Power
2340 W
Zone 3 - Power
1310 W
Zone 4 - Power
5860 W
Burners type
Standard
Burner caps
Enameled matte black
Automatic gas ignition
Yes
Gas safety valves
Yes
Zone 1 - Position
Left
Zone 2 - Position
Front-center
Zone 3 - Position
Rear-center
Zone 4 - Position
Right
Volume
0.13 cu. ft.
Cavity material
EverClean enamel
No. of shelves
4
Shelves type
Metal racks
No. of lights
2
Light type
Halogen
Light Power
40 W
Fan number
1
Time setting
Start and end
Door opening
Drop-down
Light on when door is open
Yes
Removable door
Yes
Full-glass inner door
Yes
Removable inner door
Yes
Total no. of door glasses
3
No.of thermo-reflective door glasses
2
Safety thermostat
Yes
Cooling system
Tangential
Grill type
Electric
Grill power
1700 W
Large grill - Power
2900 W
Bottom heating element - Power
1700 W
Upper heating element - Power
1200 W
Circular heating element - Power
2700 W
Soft Close system
Yes
Temperature control
Electro-mechanical
Electrical connection rating
3700 W
Current
20 A
Circuit breaker
20 A
Voltage
240/208 V
Frequency
60 Hz
Power cord length
47 1/4 "
Type of electric cable installed
Yes, Double phase
Gas Type
G20/G25 - 20/25 mbar
Dimensions
915x762x635 mm
Width
30 1/16 "
Height
36 1/16 "
Depth
25 1/16 "
Packaged dimensions
1010X870X750 mm
Gross weight
259 lbs
Net weight
233 lbs
Packaged width
34 1/4 "
Packaged depth
29 1/2 "
Packaged height
39 3/4 "
Maximum stackability
4
Packaging
Cardboard box
Packaging composition - Paper
9 lbs
Packaging composition - Polystyrene
11 lbs
Packaging composition - Wood
5 lbs
Packaging composition - Plastics
1 lbs
Other gas nozzles included
G30 LPG liquid gas
Cast iron wok support
1
Oven grid with back-stop, tray support
1
TOP Oven grid with back stop
1
Grill mesh
1
0.8"-deep tray
1
Telescopic Guide rails, partial Extraction
1
GTIN
08017709260699
EAN
8017709260699
Product family: Range
Aesthetics: Portofino
Color: Anthracite
Main oven: Thermo-ventilated
Product family
Range
Range size
30"
Range type
Dual fuel
Cooktop
Gas
N. of ovens
1
Main oven
Thermo-ventilated
EAN code
8017709260699
Installation positioning of the appliance
Free-standing, Class 1, Built-in, Class 2-1 norm UNI EN 30-1-1
Cast iron wok support
1
Oven wire rack
1
TOP Oven grid with back stop
1
Grill mesh
1
0.8"-deep tray
1
Telescopic Guide rails, partial Extraction
1
