PRODUCT DESCRIPTION
Specifications
Width
12.5 , 24 , 36 , 48
Sones
6
Extraction capacity
600 CFM
Warranty
3 Year Parts and In-Home Labor Warranty. Third year awarded after product registration on www.elica.com
SHIPPING WEIGHT (kg)
38.70
NET WEIGHT (kg)
29.50
CARTON LENGHT (mm)
781.00
CARTON HEIGHT (mm)
413.00
CARTON WIDTH (mm)
1074.00
VOLUMEN (M3)
0.30
SHIPPING WEIGHT
85.32
NET WEIGHT
65.04
CARTON LENGHT
30.75
CARTON HEIGHT
16.26
CARTON WIDTH
42.28
COUNTRY OF MANUFACTURE
PL
QTY PACKAGE
1.00
INTENDED APPROVED USE
Residential use
Finish
Stainless Steel
Color
inox
Type of Ventilation
Convertible
HOODS FEATURES
Long life filter, Special Materials, Led Light, Maintenance alarm, Total Integration, Comfort silence
WIDTH (IN)
36"
WIDTH (CM)
90.00
AIRFLOW (M3/H)
1020.00
CFM (MAX)
600.00
db (min)
36.00
db (max)
55.00
SONES
1.8 - 6.8
EXHAUST VERSION
Convertible with Kit
EXHAUST SIZE
Round 6"
DUCT SHAPE
Round
EXHAUST LOCATION
Top Only
RECTANGULAR DUCTH HEIGHT
NA
RECTANGULAR DUCT WIDTH
NA
Round duct diameter
6"
ELECTRIC (VOLTS)
120 V/60 Hz
AMPERAGE
3.8 A
HERTZ
60.00
WATTS
460.00
LIGHTING
Strip LED 1 x 7 ww 3500 KK
BULB TYPE
Strip LED
BULB INCLUDED
YES
NUMBER OF LIGHTS
1.00
BULB WATTS
7.00
KELVINS
3500.00
GREASE FILTER TYPE
Sophisticated Black Iron Grates + 6 Layer Mesh Filter
DISHWASHERSAFE FILTER
YES
FILTER MATERIAL
Iron
BLOWER TYPE
Interior Unit
CONTROL TYPE
Sensitive Touch Control with Backlight
SPEED CONTROL
YES
NUMBER OF SPEEDS
3 + booster
REMOTE CONTROL
NO
POWER SOURCE
Power Cord
OUTDOOR USE
NO
SMUDGE RESISTANT
NO
RECIRCULATION KIT NEEDED
YES
CFM REDUCTION
No
DIMENSIONS
91 x 32 x 83
DIMENSIONSinches
ADJUSTABLE HEIGHT
YES
Minimum Overall Height - Top to Bottom
32"
Maximum Overall Height - Top to Bottom
49"
Overall Height - Top to Bottom
32 -49
Overall Width - Side to Side2
36"
Overall Depth - Front to Back
15
Hood Height
32"
Minimum Compatible Ceiling Height
7'3"
Maximum Compatible Ceiling Height
10'1"
Minimum Height Above Cooktop (ELECTRIC)
= 24
Minimum Height Above Cooktop (GAS)
= 30
Maximum Height Above Cooktop
36"
Chimney Width - Side to Side
12"
Chimney Depth - Front to Back
12"
Chimney Height - Top to Bottom
49
RECIRCULATION KIT NUMBER
CFC0141725AUL
CHIMNEY EXTENSION NUMBER
-
TELESCOPIC DUCT COVER
-
DUCT TRANSITION
-
TRANSITION REDUCER KIT
-
BACKDRAFT DAMPER
-
NON RETURN VALVE
-
UPGRADE FILTER
-
CFM REDUCTION KIT
-
BACKSPLASH KIT
-
INTERNAL BLOWER
-
INLINE BLOWER
-
EXTERNAL BLOWER
-
INLINE BLOWER SHELL KIT
-
EXTERNAL BLOWER SHELL KIT
-
HEAT LAMPS
-
SPACER/LINER
-
WALL MOUNT BRACKET
-
HIGH CEILING EXTENSION KIT
-
REMOTE CONTROL KIT
-
cUL listed
YES
UL listed
YES
AHAM verified
YES
TITLE 24
YES
Prop65Disclosure
YES
ENERGY STAR
NO
WIFI CAPABLE
NO
COMERCIAL USE APPROVED
NO
ADA COMPLIANT
NO
APP CAPABLE
NO
VENTILATION DIRECTION
HORIZONTAL
SMART COMPATIBLE
NO
FITLER INDICATOR LIGHT
YES
HEAT SENSOR
NO
CHAROCAL FILTER
YES
CERTIFICADO NOM
Activo
DIMENSIONS inches
36" x 12 3/5-15 x 32"
Prop65 Disclosure
YES
GTIN
00190603003949
EAN
0190603003949
UPC
190603003949
Long life filter
Special Materials
Led Light
Maintenance alarm
Total Integration
Comfort silence
