PRODUCT DESCRIPTION
Specifications
Brand
Zephyr
Manufacturer
Zephyr
Category
Range Hood
Sub-Category
Wall
Vent Type
Convertible
UPC
646328008498
GTIN
00646328008498
Country of Origin
Taiwan
Model Group
ZVE-D
Model Name
Venezia Wall
Collection
Core Collection
Blower Included
Yes
Blower CFM w/ACT
590, 390, 290
Internal Blower 1 CFM
700
Internal Blower 1 Min. Sones
0.8
Internal Blower 1 Max Sones
6
Minimum CFM
200
Installation Type
Wall
For Outdoor Use
No
Color
Stainless Steel
Controls Type
Proximity Touch
Blower Speeds
6
Automatic Delay-Off
Yes
Clean Air Function
Yes
Lighting Type
LED
Lights Quantity
2
Watts Per Bulb
6
Lights Levels
3
Grease Filter Type
Hybrid Baffle
Compatible Mesh or Baffle Filter Part Number
50210041
Duct Discharge
Vertical
Duct Size; Vertical; IN
8
Mounting Height Above Cooktop; IN
24 - 36
Voltage
120
Maximum Amperage
5
ADA Compliant
Yes, with optional remote
Warranty Parts / Labor
3 / 1
Compatible Appliances
14000005, ZRC-03VE, Z1C-01VE, MUA008A, Z0F-C005, AK1712
Bluetooth Connected
No
Wi-Fi Connected
Yes
Remote Included
No
Remote Optional
Yes
Energy Star Certified
No
Alexa & Google Home Compatible
Yes
CEC Title 20 Compliant
Yes
CEC Title 24 Compliant
Yes
Primary Material
Stainless Steel
Wattage
600
Certification
UL
Nominal Width; IN
42
Net Width; IN
41.875
Net Depth; IN
24
Net Height; IN
27 - 44
Weight; LBS
50.000
Ceiling Height Minimum
8 ft.
Ceiling Height Maximum
9.5 ft.
Chimney Height in.
16.75
Chimney Width in.
14.18
Chimney Depth in.
10.56
Shipping Length; IN
46.85
Shipping Width; IN
15.75
Shipping Height; IN
30.08
Shipping Weight; LBS
57.3
Shipping Method
LTL
Freight Class
300
Certification #
E127334
Clean Filter Alert
Yes
Duct Type
Vertical
GTIN
00646328008498
EAN
0646328008498
UPC
646328008498
LumiLight LED Lighting
Airflow Control Technology(TM) (ACT(TM))
Compatible with Zephyr Connect App
CleanAir Function
Optional Ductless Recirculating Kit
Optional Extension Duct Cover Kit
Optional Wireless Remote Control (14000005)
