PRODUCT DESCRIPTION
Specifications
Brand
Zephyr
Manufacturer
Zephyr
Category
Range Hood
Sub-Category
Wall
Vent Type
Ducted
UPC
646328012310
GTIN
00646328012310
Country of Origin
Taiwan
Model Group
ZSP-D
Model Name
Siena Pro Wall
Collection
Core Collection
Blower Included
Yes
Blower CFM w/ACT
590, 390
Internal Blower 1 CFM
1200
Internal Blower 1 Min. Sones
2
Internal Blower 1 Max Sones
9
Minimum CFM
350
Installation Type
Wall
For Outdoor Use
No
Color
Stainless Steel
Controls Type
ICON Touch(R)
Blower Speeds
5
Automatic Delay-Off
Yes
Clean Air Function
No
Lighting Type
LED
Lights Quantity
2
Watts Per Bulb
6
Lights Levels
2
Grease Filter Type
Hybrid Baffle
Compatible Mesh or Baffle Filter Part Number
50210041
Duct Discharge
Vertical
Duct Size; Horizontal; IN
N/A
Duct Size; Vertical; IN
10
Mounting Height Above Cooktop; IN
24 - 34
Voltage
120
Maximum Amperage
9
ADA Compliant
Yes, with optional remote
Warranty Parts / Labor
3 / 1
Compatible Appliances
RC-0002, Z1C-00SP, AK1716, MUA010A
Bluetooth Connected
No
Wi-Fi Connected
No
Remote Included
No
Remote Optional
Yes
Energy Star Certified
No
Alexa & Google Home Compatible
No
CEC Title 20 Compliant
Yes
CEC Title 24 Compliant
Yes
Primary Material
Stainless Steel
Wattage
1080
Certification
UL
Nominal Width; IN
36
Net Width; IN
35.9375
Net Depth; IN
24
Net Height; IN
29 - 42
Weight; LBS
47
Ceiling Height Minimum
8 ft.
Ceiling Height Maximum
9 ft.
Chimney Height in.
17
Chimney Width in.
16.68
Chimney Depth in.
12.18
Shipping Length; IN
48
Shipping Width; IN
45
Shipping Height; IN
36
Shipping Weight; LBS
115
Shipping Method
LTL
Freight Class
250
Certification #
E127334
Clean Filter Alert
Yes
Duct Type
Vertical
GTIN
00646328012310
EAN
0646328012310
UPC
646328012310
Airflow Control Technology(TM) (ACT(TM))
ICON Touch(R) LCD Controls
Hybrid Baffle Filters
LumiLight LED Lighting with TruHue(TM)
Powerful 1200-CFM Blowers
Optional Extension Duct Cover Kit
Optional Wireless Remote Control (RC-0002)
