PRODUCT DESCRIPTION
Specifications
Brand
Zephyr
Manufacturer
Zephyr
Category
Range Hood
Sub-Category
Island
Vent Type
Convertible
UPC
646328006623
GTIN
00646328006623
Country of Origin
Taiwan
Model Group
ZRE-A
Model Name
Ravenna Island
Collection
Core Collection
Replacement Model
ZRE-E42BBSGG
Blower Included
Yes
Blower CFM w/ACT
390, 290
Internal Blower 1 CFM
600
Internal Blower 1 Min. Sones
1
Internal Blower 1 Max Sones
6
Minimum CFM
200
Installation Type
Island
For Outdoor Use
No
Color
Stainless Steel + Glass
Controls Type
ICON Touch(R)
Blower Speeds
5
Automatic Delay-Off
Yes
Clean Air Function
No
Lighting Type
LED
Lights Quantity
2
Watts Per Bulb
9
Lights Levels
2
Grease Filter Type
Mesh
Compatible Mesh or Baffle Filter Part Number
50200043
Duct Discharge
Vertical
Duct Size; Horizontal; IN
N/A
Duct Size; Vertical; IN
6
Mounting Height Above Cooktop; IN
26 - 34
Voltage
120
Maximum Amperage
4
ADA Compliant
No
Warranty Parts / Labor
3 / 1
Compatible Appliances
ZRC-00RE, Z1C-00REBS, MUA006A, Z0F-C002
Bluetooth Connected
No
Wi-Fi Connected
No
Remote Included
No
Remote Optional
No
Energy Star Certified
No
Alexa & Google Home Compatible
No
CEC Title 20 Compliant
Yes
Primary Material
Steel
Wattage
480
Certification
UL
Nominal Width; IN
42
Net Width; IN
41.9375
Net Depth; IN
25.5625
Net Height; IN
28.5 - 38
Weight; LBS
88
Ceiling Height Minimum
8 ft.
Ceiling Height Maximum
9 ft.
Chimney Height in.
25
Chimney Width in.
10.37
Chimney Depth in.
10.87
Shipping Length; IN
46.65
Shipping Width; IN
30.71
Shipping Height; IN
24.17
Shipping Weight; LBS
110.9
Shipping Method
LTL
Freight Class
250
Certification #
E127334
Clean Filter Alert
Yes
Duct Type
Vertical
GTIN
00646328006623
EAN
0646328006623
UPC
646328006623
Airflow Control Technology(TM) (ACT(TM))
ICON Touch(R) Controls
Quick-Lock Installation System
BriteStrip(TM) LED Lighting
Dual-Level Lighting
Optional Ductless Recirculating Kit
Optional Extension Duct Cover Kit
