PRODUCT DESCRIPTION
Specifications
Brand
Zephyr
Manufacturer
Zephyr
Category
Range Hood
Sub-Category
Wall
Vent Type
Convertible
UPC
646328009587
GTIN
00646328009587
Country of Origin
Taiwan
Model Group
ZOM-B
Model Name
Ombra Wall
Collection
Core Collection
Blower Included
Yes
Blower CFM w/ACT
390, 290
Internal Blower 1 CFM
600
Internal Blower 1 Min. Sones
1
Internal Blower 1 Max Sones
6
Minimum CFM
200
Installation Type
Wall
For Outdoor Use
No
Color
Black Stainless Steel
Controls Type
Capacitive Touch
Blower Speeds
4
Automatic Delay-Off
Yes
Clean Air Function
No
Lighting Type
LED
Lights Quantity
2
Watts Per Bulb
6
Lights Levels
2
Grease Filter Type
Mesh
Compatible Mesh or Baffle Filter Part Number
50200059
Duct Discharge
Vertical
Duct Size; Vertical; IN
6
Mounting Height Above Cooktop; IN
24 - 34
Voltage
120
Maximum Amperage
4
ADA Compliant
No
Warranty Parts / Labor
3 / 1
Compatible Appliances
ZRC-01OM, Z1C-01OMBS, Z0F-B002, MUA006A, Z0F-C091, AK1716
Bluetooth Connected
No
Wi-Fi Connected
No
Remote Included
No
Remote Optional
No
Energy Star Certified
No
Alexa & Google Home Compatible
No
CEC Title 20 Compliant
Yes
CEC Title 24 Compliant
Yes
Primary Material
Steel
Wattage
480
Certification
UL
Nominal Width; IN
30
Net Width; IN
29.875
Net Depth; IN
19.75
Net Height; IN
30
Weight; LBS
26
Ceiling Height Minimum
8 ft.
Ceiling Height Maximum
10 ft.
Chimney Height in.
18
Chimney Width in.
8.75
Chimney Depth in.
6.87
Shipping Length; IN
34.84
Shipping Width; IN
16.34
Shipping Height; IN
25.6
Shipping Weight; LBS
35
Shipping Method
Small Parcel
Freight Class
250
Certification #
E127334
Clean Filter Alert
Yes
Duct Type
Vertical
GTIN
00646328009587
EAN
0646328009587
UPC
646328009587
Airflow Control Technology(TM) (ACT(TM))
LumiLight LED Lighting
Dual-Level Lighting
Dishwasher Safe Aluminum Mesh Filters
Capacitive Touch Controls
Optional Ductless Recirculating Kit
Optional Extension Duct Cover Kit
