PRODUCT DESCRIPTION
Specifications
Brand
Zephyr
Manufacturer
Zephyr
Category
Range Hood
Sub-Category
Wall
Vent Type
Convertible
UPC
646328008191
GTIN
00646328008191
Country of Origin
Taiwan
Model Group
ZMO-B
Model Name
Modena Wall
Collection
Core Collection
Blower Included
Yes
Blower CFM w/ACT
390, 290
Internal Blower 1 CFM
600
Internal Blower 1 Min. Sones
1
Internal Blower 1 Max Sones
6
Minimum CFM
200
Installation Type
Wall
For Outdoor Use
No
Color
Stainless Steel
Controls Type
ICON Touch(R)
Blower Speeds
5
Automatic Delay-Off
Yes
Clean Air Function
No
Lighting Type
LED
Lights Quantity
2
Watts Per Bulb
6
Lights Levels
2
Grease Filter Type
Mesh
Compatible Mesh or Baffle Filter Part Number
50200042
Duct Discharge
Vertical
Duct Size; Vertical; IN
8
Mounting Height Above Cooktop; IN
24 - 34
Voltage
120
Maximum Amperage
4
ADA Compliant
No
Warranty Parts / Labor
3 / 1
Compatible Appliances
ZRC-00MO, Z1C-00MO, MUA006A, Z0F-C002, AK1710
Bluetooth Connected
No
Wi-Fi Connected
No
Remote Included
No
Remote Optional
No
Energy Star Certified
No
Alexa & Google Home Compatible
No
CEC Title 20 Compliant
Yes
CEC Title 24 Compliant
Yes
Primary Material
Stainless Steel
Wattage
480
Certification
UL
Nominal Width; IN
30
Net Width; IN
29.9
Net Depth; IN
22.125
Net Height; IN
27 - 50
Weight; LBS
69.500
Ceiling Height Minimum
8 ft.
Ceiling Height Maximum
10 ft.
Chimney Height in.
25.5
Chimney Width in.
13.37
Chimney Depth in.
12.37
Shipping Length; IN
26.5
Shipping Width; IN
36.6
Shipping Height; IN
29.7
Shipping Weight; LBS
74.7
Shipping Method
LTL
Freight Class
300
Certification #
E127334
Clean Filter Alert
Yes
Duct Type
Vertical
GTIN
00646328008191
EAN
0646328008191
UPC
646328008191
LumiLight LED Lighting
Airflow Control Technology(TM) (ACT(TM))
ICON Touch(R) Controls
Dishwasher Safe Aluminum Mesh Filters
Low-profile body
Optional Ductless Recirculating Kit
Optional Extension Duct Cover Kit
