PRODUCT DESCRIPTION
Specifications
Brand
Zephyr
Manufacturer
Zephyr
Category
Range Hood
Sub-Category
Under Cabinet
Vent Type
Ducted
UPC
646328454837
GTIN
00646328454837
Country of Origin
Taiwan
Model Group
CCA
Model Name
Cache
Collection
Designer Collection
Blower Included
No
Internal Blower 1 CFM
290
Internal Blower 1 Min. Sones
1.4
Internal Blower 1 Max Sones
3
Internal Blower 2 CFM
600
Internal Blower 2 Max Sones
6
In-Line Blower CFM
1000
External Blower CFM
1000
Installation Type
Under Cabinet
For Outdoor Use
No
Color
Stainless Steel
Controls Type
Electronic
Blower Speeds
3
Automatic Delay-Off
Yes
Clean Air Function
No
Lighting Type
Halogen
Lights Quantity
4
Watts Per Bulb
50
Lights Levels
2
Grease Filter Type
Pro baffle
Compatible Mesh or Baffle Filter Part Number
50210004
Duct Discharge
Vertical or Horizontal
Duct Size; Horizontal; IN
3.25 x 10
Duct Size; Vertical; IN
6, 8
Mounting Height Above Cooktop; IN
24 - 36
Voltage
120
Maximum Amperage
6.5
ADA Compliant
Yes, with optional remote
Warranty Parts / Labor
3 / 1
Compatible Appliances
MUA006A, MUA008A, Z0B0040
Bluetooth Connected
No
Wi-Fi Connected
No
Remote Included
No
Remote Optional
Yes
Energy Star Certified
No
Alexa & Google Home Compatible
No
CEC Title 20 Compliant
Yes
Primary Material
Stainless Steel
Certification
UL
Nominal Width; IN
48
Net Width; IN
47.9375
Net Depth; IN
22.125
Net Height; IN
10.375
Weight; LBS
59.52
Ceiling Height Minimum
8 ft.
Ceiling Height Maximum
12 ft.
Shipping Length; IN
15.16
Shipping Width; IN
51.77
Shipping Height; IN
28.74
Shipping Weight; LBS
67.24
Shipping Method
LTL
Freight Class
300
Duct Type
Vertical
GTIN
00646328454837
EAN
0646328454837
UPC
646328454837
Multiple blower options
Professional Baffle Filters
