PRODUCT DESCRIPTION
Specifications
Brand
Zephyr
Manufacturer
Zephyr
Category
Range Hood
Sub-Category
Insert
Vent Type
Convertible
UPC
646328009907
GTIN
00646328009907
Country of Origin
Taiwan
Model Group
AK95-A
Model Name
Monsoon Mini II Insert
Collection
Core Collection
Blower Included
Yes
Blower CFM w/ACT
390, 290
Internal Blower 1 CFM
600
Internal Blower 1 Min. Sones
1.4
Internal Blower 1 Max Sones
6
Minimum CFM
200
Installation Type
Insert
For Outdoor Use
No
Color
Stainless Steel
Controls Type
Electronic
Blower Speeds
3
Automatic Delay-Off
Yes
Clean Air Function
No
Lighting Type
LED
Lights Quantity
2
Watts Per Bulb
6
Lights Levels
2
Grease Filter Type
Hybrid Baffle
Compatible Mesh or Baffle Filter Part Number
50210041
Duct Discharge
Vertical or Horizontal
Duct Size; Horizontal; IN
3.25 x 10
Duct Size; Vertical; IN
7, 3.25 x 10
Mounting Height Above Cooktop; IN
24 - 34
Voltage
120
Maximum Amperage
2
ADA Compliant
No
Warranty Parts / Labor
3 / 1
Compatible Appliances
ZRC-9100A, Z0F-C091, AK00067, MUA006A
Bluetooth Connected
No
Wi-Fi Connected
No
Remote Included
No
Remote Optional
No
Energy Star Certified
No
Alexa & Google Home Compatible
No
CEC Title 20 Compliant
Yes
CEC Title 24 Compliant
Yes
Primary Material
Stainless Steel
Wattage
240
Certification
UL
Nominal Width; IN
30
Net Width; IN
28.375
Net Depth; IN
17.875
Net Height; IN
6.125
Weight; LBS
30.5
Ceiling Height Minimum
8 ft.
Ceiling Height Maximum
12 ft.
Shipping Length; IN
33
Shipping Width; IN
9
Shipping Height; IN
23
Shipping Weight; LBS
36
Shipping Method
Small Parcel
Freight Class
100
Certification #
E127334
Clean Filter Alert
Yes
Cutout Depth in.
18
Cutout Width in.
28.5
Duct Type
Vertical
GTIN
00646328009907
EAN
0646328009907
UPC
646328009907
Electronic Touch Controls
3 Speed Levels
LumiLight LED Lighting
Dual-Level Lighting
Hybrid Baffle Filters
Vertical or horizontal ducting
Optional Ductless Recirculating Kit
