PRODUCT DESCRIPTION
Specifications
Brand
Zephyr
Manufacturer
Zephyr
Category
Range Hood
Sub-Category
Insert
Vent Type
Ducted
UPC
646328008320
GTIN
00646328008320
Country of Origin
Taiwan
Model Group
AK93-B
Model Name
Monsoon II Insert
Collection
Pro Collection
Blower Included
Yes
Blower CFM w/ACT
590, 390
Internal Blower 1 CFM
1200
Internal Blower 1 Min. Sones
3.5
Internal Blower 1 Max Sones
9
Minimum CFM
450
Installation Type
Insert
For Outdoor Use
No
Color
Stainless Steel
Controls Type
Electronic
Blower Speeds
6
Automatic Delay-Off
Yes
Clean Air Function
Yes
Lighting Type
LED
Lights Quantity
4
Watts Per Bulb
6
Lights Levels
2
Grease Filter Type
Pro baffle
Compatible Mesh or Baffle Filter Part Number
50210033
Duct Discharge
Vertical
Duct Size; Vertical; IN
10
Mounting Height Above Cooktop; IN
26 - 36
Voltage
120
Maximum Amperage
7
ADA Compliant
Yes
Warranty Parts / Labor
3 / 1
Compatible Appliances
MUA010A, Z0B0040, 14000005
Bluetooth Connected
No
Wi-Fi Connected
No
Remote Included
Yes
Remote Optional
No
Energy Star Certified
No
Alexa & Google Home Compatible
No
CEC Title 20 Compliant
Yes
CEC Title 24 Compliant
Yes
Primary Material
Stainless Steel
Wattage
840
Certification
UL
Nominal Width; IN
42
Net Width; IN
40.375
Net Depth; IN
22.5
Net Height; IN
12
Weight; LBS
59.1
Ceiling Height Minimum
8 ft.
Ceiling Height Maximum
12 ft.
Shipping Length; IN
16.5
Shipping Width; IN
43.3
Shipping Height; IN
28.3
Shipping Weight; LBS
71.8
Shipping Method
LTL
Freight Class
300
Certification #
E127334
Clean Filter Alert
Yes
Cutout Depth in.
22.75
Cutout Width in.
40.625
Duct Type
Vertical
GTIN
00646328008320
EAN
0646328008320
UPC
646328008320
Airflow Control Technology(TM) (ACT(TM))
LumiLight LED Lighting
Includes wireless remote control
Professional Baffle Filters
Electronic Touch Controls
Powerful 1200-CFM Blowers
CleanAir Function
