PRODUCT DESCRIPTION
Specifications
Brand
Zephyr
Manufacturer
Zephyr
Category
Range Hood
Sub-Category
Insert
Vent Type
Ducted
UPC
646328011597
GTIN
00646328011597
Country of Origin
Taiwan
Model Group
AK84-ES-B
Model Name
Tornado Mini Insert ENERGY STAR(R)
Collection
Core Collection
Blower Included
Yes
Internal Blower 1 CFM
290
Internal Blower 1 Min. Sones
1.3
Internal Blower 1 Max Sones
3.2
Minimum CFM
180
Installation Type
Insert
For Outdoor Use
No
Color
Stainless Steel
Controls Type
Mechanical Slide
Blower Speeds
3
Automatic Delay-Off
No
Clean Air Function
No
Lighting Type
LED
Lights Quantity
2
Watts Per Bulb
6
Lights Levels
2
Grease Filter Type
Mesh
Compatible Mesh or Baffle Filter Part Number
50200054
Duct Discharge
Vertical
Duct Size; Vertical; IN
6
Mounting Height Above Cooktop; IN
20 - 36
Voltage
120
Maximum Amperage
2
ADA Compliant
No
Warranty Parts / Labor
3 / 1
Compatible Appliances
AK0840AS, AK0846AS
Bluetooth Connected
No
Wi-Fi Connected
No
Remote Included
No
Remote Optional
No
Energy Star Certified
Yes
Alexa & Google Home Compatible
No
CEC Title 20 Compliant
Yes
CEC Title 24 Compliant
Yes
Primary Material
Stainless Steel
Wattage
240
Certification
UL
Nominal Width; IN
21
Net Width; IN
20.562
Net Depth; IN
11
Net Height; IN
9.687
Weight; LBS
14
Ceiling Height Minimum
8 ft.
Ceiling Height Maximum
12 ft.
Shipping Length; IN
25
Shipping Width; IN
14
Shipping Height; IN
15
Shipping Weight; LBS
18
Shipping Method
Small Parcel
Freight Class
150
Certification #
E127334
Clean Filter Alert
No
Cutout Depth in.
10.25
Cutout Width in.
19.75
Duct Type
Vertical
GTIN
00646328011597
EAN
0646328011597
UPC
646328011597
ENERGY STAR(R) Certified
Mechanical Slide Controls
3 Speed Levels
Dual-Level Lighting
Dishwasher Safe Aluminum Mesh Filters
Optional Adjustable Depth Liner
LumiLight LED Lighting
