PRODUCT DESCRIPTION
Specifications
Brand
Zephyr
Manufacturer
Zephyr
Category
Range Hood
Sub-Category
Insert
Vent Type
Ducted
UPC
646328013171
GTIN
00646328013171
Country of Origin
Taiwan
Model Group
AK83-A
Model Name
Tornado III Insert
Collection
Pro Collection
Blower Included
No
Internal Blower 1 CFM
390
Internal Blower 1 Min. Sones
1.4
Internal Blower 1 Max Sones
5
Internal Blower 2 CFM
600
Internal Blower 3 CFM
1000
In-Line Blower CFM
1000
External Blower CFM
1000
Minimum CFM
200
Installation Type
Insert
For Outdoor Use
No
Color
Stainless Steel
Controls Type
Electronic
Blower Speeds
3
Automatic Delay-Off
Yes
Clean Air Function
No
Lighting Type
LED
Lights Quantity
2
Watts Per Bulb
6
Lights Levels
3
Grease Filter Type
Pro baffle
Compatible Mesh or Baffle Filter Part Number
50210054
Duct Discharge
Vertical
Duct Size; Horizontal; IN
N/A
Duct Size; Vertical; IN
6
Mounting Height Above Cooktop; IN
24 - 36
Voltage
120
Maximum Amperage
5.8
ADA Compliant
Yes, with optional remote
Warranty Parts / Labor
3 / 1
Compatible Appliances
CBI-290C, CBI-390A, CBI-600A, PBI-1000B, CBE-1000, PBN-1000A, AK083480AS, AK083481AS, MUA006A, MUA010A, 14000005
Bluetooth Connected
No
Wi-Fi Connected
No
Remote Included
No
Remote Optional
Yes
Energy Star Certified
No
Alexa & Google Home Compatible
No
CEC Title 20 Compliant
Yes
Primary Material
Stainless Steel
Wattage
760
Certification
UL
Nominal Width; IN
40
Net Width; IN
40.25
Net Depth; IN
14.9
Net Height; IN
12
Weight; LBS
22.7
Ceiling Height Minimum
8 ft.
Ceiling Height Maximum
12 ft.
Shipping Length; IN
44.6
Shipping Width; IN
17.4
Shipping Height; IN
19.6
Shipping Weight; LBS
39.2
Shipping Method
Small Parcel
Freight Class
175
Certification #
E127334
Clean Filter Alert
Yes
Duct Type
Vertical
LumiLight LED Lighting with TruHue(TM)
Professional Baffle Filters
Electronic Touch Controls
Dual-Level Lighting
Multiple Blower Options
Optional Wireless Remote Control (14000005)
Optional Liner Accessories Available
