PRODUCT DESCRIPTION
Specifications
Brand
Zephyr
Manufacturer
Zephyr
Category
Range Hood
Sub-Category
Insert
Vent Type
Ducted
UPC
646328013065
GTIN
00646328013065
Country of Origin
Taiwan
Model Group
AK82-A
Model Name
Tornado II Insert
Collection
Pro Collection
Blower Included
Yes
Internal Blower 1 CFM
600
Internal Blower 1 Min. Sones
1.8
Internal Blower 1 Max Sones
6
Internal Blower 2 CFM
1000
Minimum CFM
200
Installation Type
Insert
For Outdoor Use
No
Color
Stainless Steel
Controls Type
Electronic
Blower Speeds
5
Automatic Delay-Off
Yes
Clean Air Function
No
Lighting Type
LED
Lights Quantity
2
Watts Per Bulb
6
Lights Levels
2
Grease Filter Type
Pro baffle
Compatible Mesh or Baffle Filter Part Number
50210054
Duct Discharge
Vertical
Duct Size; Horizontal; IN
N/A
Duct Size; Vertical; IN
6
Mounting Height Above Cooktop; IN
24 - 36
Voltage
120
Maximum Amperage
3
ADA Compliant
Yes, with optional remote
Warranty Parts / Labor
3 / 1
Compatible Appliances
PBD-1000A, AK082360AS, MUA006A, 14000005
Bluetooth Connected
No
Wi-Fi Connected
No
Remote Included
No
Remote Optional
Yes
Energy Star Certified
No
Alexa & Google Home Compatible
No
CEC Title 20 Compliant
Yes
Primary Material
Stainless Steel
Wattage
360
Certification
UL
Nominal Width; IN
27
Net Width; IN
27.3
Net Depth; IN
14.9
Net Height; IN
14.5
Weight; LBS
25.4
Ceiling Height Minimum
8 ft.
Ceiling Height Maximum
12 ft.
Shipping Length; IN
31.3
Shipping Width; IN
17.4
Shipping Height; IN
19.6
Shipping Weight; LBS
38.6
Shipping Method
Small Parcel
Freight Class
175
Certification #
E127334
Clean Filter Alert
Yes
Duct Type
Vertical
LumiLight LED Lighting with TruHue(TM)
Professional Baffle Filters
Electronic Touch Controls
Dual-Level Lighting
Optional Dual Internal Blower Kit Available
Optional Wireless Remote Control (14000005)
Optional Liner Accessories Available
