PRODUCT DESCRIPTION
Specifications
Brand
Zephyr
Manufacturer
Zephyr
Category
Range Hood
Sub-Category
Wall
Vent Type
Ducted
UPC
646328010583
GTIN
00646328010583
Country of Origin
Taiwan
Model Group
AK78-C
Model Name
Cypress Wall Outdoor
Collection
Pro Collection
Blower Included
Yes
Internal Blower 1 CFM
1200
Internal Blower 1 Min. Sones
3.5
Internal Blower 1 Max Sones
9
Minimum CFM
450
Installation Type
Wall
For Outdoor Use
Yes
Color
Stainless Steel
Controls Type
Control Knob
Blower Speeds
3
Automatic Delay-Off
No
Clean Air Function
No
Lighting Type
LED
Lights Quantity
2
Watts Per Bulb
6
Lights Levels
2
Grease Filter Type
Pro baffle
Compatible Mesh or Baffle Filter Part Number
50210031
Duct Discharge
Vertical or Horizontal
Duct Size; Horizontal; IN
10
Duct Size; Vertical; IN
10
Mounting Height Above Cooktop; IN
32-42
Voltage
120
Maximum Amperage
9
ADA Compliant
No
Warranty Parts / Labor
3 / 1
Compatible Appliances
AK0736BS, Z1C-0178
Bluetooth Connected
No
Wi-Fi Connected
No
Remote Included
No
Remote Optional
No
Energy Star Certified
No
Alexa & Google Home Compatible
No
CEC Title 20 Compliant
Yes
Primary Material
Stainless Steel
Wattage
1080
Certification
UL
Nominal Width; IN
36
Net Width; IN
35.875
Net Depth; IN
32
Net Height; IN
18
Weight; LBS
84
Ceiling Height Minimum
8 ft.
Ceiling Height Maximum
12 ft.
Shipping Length; IN
35.04
Shipping Width; IN
38.58
Shipping Height; IN
22.63
Shipping Weight; LBS
98.32
Shipping Method
LTL
Freight Class
250
Certification #
E127334
Duct Type
Vertical
GTIN
00646328010583
EAN
0646328010583
UPC
646328010583
High-grade Stainless Steel
Outdoor Rated
Professional Baffle Filters
Welded and polished body
Vertical or horizontal ducting
Metallic Knob Controls
Optional Extension Duct Cover Kit
Welded and and polished body
