PRODUCT DESCRIPTION
Specifications
Brand
Zephyr
Manufacturer
Zephyr
Category
Range Hood
Sub-Category
Island
Vent Type
Ducted
UPC
646328007743
GTIN
00646328007743
Country of Origin
Taiwan
Model Group
AK77
Model Name
Titan Island
Collection
Pro Collection
Replacement Model
AK7736BS
Blower Included
Yes
Blower CFM w/ACT
590, 390, 290
Internal Blower 1 CFM
750
Internal Blower 1 Min. Sones
0.5
Internal Blower 1 Max Sones
7
Internal Blower 2 CFM
1300
Internal Blower 2 Max Sones
8
Minimum CFM
200
Installation Type
Island
For Outdoor Use
No
Color
Stainless Steel
Controls Type
Electronic LCD
Blower Speeds
6
Automatic Delay-Off
Yes
Clean Air Function
Yes
Lighting Type
LED
Lights Quantity
2
Watts Per Bulb
6
Lights Levels
2
Grease Filter Type
Pro baffle
Compatible Mesh or Baffle Filter Part Number
50210036
Duct Discharge
Vertical
Duct Size; Horizontal; IN
N/A
Duct Size; Vertical; IN
8
Mounting Height Above Cooktop; IN
24 - 36
Voltage
120
Maximum Amperage
4
ADA Compliant
Yes, with optional remote
Warranty Parts / Labor
3 / 1
Compatible Appliances
PBD-1300A, Z1C-0077, 14000005, MUA008A, MUA010A
Bluetooth Connected
No
Wi-Fi Connected
No
Remote Included
No
Remote Optional
Yes
Energy Star Certified
No
Alexa & Google Home Compatible
No
CEC Title 20 Compliant
Yes
Primary Material
Stainless Steel
Wattage
300
Certification
UL
Nominal Width; IN
36
Net Width; IN
35.9375
Net Depth; IN
31.625
Net Height; IN
33 - 50
Weight; LBS
121.2
Ceiling Height Minimum
8 ft.
Ceiling Height Maximum
10 ft.
Chimney Height in.
18.5
Chimney Width in.
17.93
Chimney Depth in.
16.25
Shipping Length; IN
40.75
Shipping Width; IN
37.2
Shipping Height; IN
36.42
Shipping Weight; LBS
131.2
Shipping Method
LTL
Freight Class
250
Certification #
E127334
Clean Filter Alert
Yes
Duct Type
Vertical
GTIN
00646328007743
EAN
0646328007743
UPC
646328007743
Airflow Control Technology(TM) (ACT(TM))
Professional Baffle Filters
Directional Lighting
CleanAir Function
Multiple Blower Options
Optional wireless remote control
Optional Extension Duct Cover Kit
