PRODUCT DESCRIPTION
Specifications
Brand
Zephyr
Manufacturer
Zephyr
Category
Range Hood
Sub-Category
Wall
Vent Type
Ducted
UPC
646328010545
GTIN
00646328010545
Country of Origin
Taiwan
Model Group
AK76-B
Model Name
Titan Wall
Collection
Pro Collection
Blower Included
Yes
Blower CFM w/ACT
590, 390, 290
Internal Blower 1 CFM
750
Internal Blower 1 Min. Sones
0.5
Internal Blower 1 Max Sones
7
Minimum CFM
200
Installation Type
Wall
For Outdoor Use
No
Color
Stainless Steel
Controls Type
Electronic LCD
Blower Speeds
6
Automatic Delay-Off
Yes
Clean Air Function
Yes
Lighting Type
LED
Lights Quantity
4
Watts Per Bulb
6
Lights Levels
2
Grease Filter Type
Pro baffle
Compatible Mesh or Baffle Filter Part Number
50210031
Duct Discharge
Vertical or Horizontal
Duct Size; Horizontal; IN
8, 10
Duct Size; Vertical; IN
8, 10
Mounting Height Above Cooktop; IN
24 - 36
Voltage
120
Maximum Amperage
8
ADA Compliant
Yes, with optional remote
Warranty Parts / Labor
3 / 1
Compatible Appliances
PBD-1300B, Z1C-0176, 14000005, MUA008A, MUA010A
Bluetooth Connected
No
Wi-Fi Connected
No
Remote Included
No
Remote Optional
Yes
Energy Star Certified
No
Alexa & Google Home Compatible
No
CEC Title 20 Compliant
Yes
CEC Title 24 Compliant
Yes
Primary Material
Stainless Steel
Wattage
300
Certification
UL
Nominal Width; IN
60
Net Width; IN
59.875
Net Depth; IN
24
Net Height; IN
30 - 42.5
Weight; LBS
105
Ceiling Height Minimum
8 ft.
Ceiling Height Maximum
9 ft.
Chimney Height in.
15.5
Chimney Width in.
22
Chimney Depth in.
13.93
Shipping Length; IN
68
Shipping Width; IN
45
Shipping Height; IN
35
Shipping Weight; LBS
163
Shipping Method
LTL
Freight Class
250
Certification #
E127334
Duct Type
Vertical
GTIN
00646328010545
EAN
0646328010545
UPC
646328010545
Airflow Control Technology(TM) (ACT(TM))
Professional Baffle Filters
Tri-Level Lighting
Welded and polished body
CleanAir Function
Optional Wireless Remote Control (14000005)
Optional Extension Duct Cover Kit
