PRODUCT DESCRIPTION
Specifications
Brand
Zephyr
Manufacturer
Zephyr
Category
Range Hood
Sub-Category
Wall
Vent Type
Ducted
UPC
646328013447
GTIN
00646328013447
Country of Origin
Taiwan
Model Group
AK76-C
Model Name
Titan Wall
Collection
Pro Collection
Blower Included
Yes
Blower CFM w/ACT
390, 290
Internal Blower 1 CFM
650
Internal Blower 1 Min. Sones
1
Internal Blower 1 Max Sones
6
Minimum CFM
200
Installation Type
Wall
For Outdoor Use
No
Color
Stainless Steel
Controls Type
Electronic
Blower Speeds
5
Automatic Delay-Off
Yes
Clean Air Function
Yes
Lighting Type
LED
Lights Quantity
2
Watts Per Bulb
6
Lights Levels
2
Grease Filter Type
Pro baffle
Compatible Mesh or Baffle Filter Part Number
50210055
Duct Discharge
Vertical or Horizontal
Duct Size; Horizontal; IN
8, 10
Duct Size; Vertical; IN
8, 10
Mounting Height Above Cooktop; IN
24 - 36
Voltage
120
Maximum Amperage
8
ADA Compliant
Yes, with optional remote
Warranty Parts / Labor
3 / 1
Compatible Appliances
PBD-1200B, Z1C-0076, RC-0002, MUA008A, MUA010A, AK1716
Bluetooth Connected
No
Wi-Fi Connected
No
Remote Included
No
Remote Optional
Yes
Energy Star Certified
No
Alexa & Google Home Compatible
No
CEC Title 20 Compliant
Yes
CEC Title 24 Compliant
Yes
Primary Material
Stainless Steel
Wattage
300
Certification
UL
Nominal Width; IN
36
Net Width; IN
35.9375
Net Depth; IN
24
Net Height; IN
30 - 42.5
Weight; LBS
61.9
Ceiling Height Minimum
8 ft.
Ceiling Height Maximum
9 ft.
Chimney Height in.
15.5
Chimney Width in.
15.87
Chimney Depth in.
13.93
Shipping Length; IN
37.87
Shipping Width; IN
18.7
Shipping Height; IN
27.6
Shipping Weight; LBS
83.1
Shipping Method
LTL
Freight Class
250
Certification #
E127334
Duct Type
Vertical
GTIN
00646328013447
EAN
0646328013447
UPC
646328013447
