PRODUCT DESCRIPTION
Specifications
Brand
Zephyr
Manufacturer
Zephyr
Category
Range Hood
Sub-Category
Under Cabinet
Vent Type
Convertible
UPC
646328009204
GTIN
00646328009204
Country of Origin
Taiwan
Model Group
AK73-A
Model Name
Tidal I Under-Cabinet
Collection
Pro Collection
Blower Included
Yes
Blower CFM w/ACT
590, 390, 290
Internal Blower 1 CFM
700
Internal Blower 1 Min. Sones
0.8
Internal Blower 1 Max Sones
6
Internal Blower 2 CFM
1300
Minimum CFM
200
Installation Type
Under Cabinet
For Outdoor Use
No
Color
Stainless Steel
Controls Type
Proximity Touch
Blower Speeds
6
Automatic Delay-Off
Yes
Clean Air Function
Yes
Lighting Type
LED
Lights Quantity
2
Watts Per Bulb
6
Lights Levels
3
Grease Filter Type
Pro baffle
Compatible Mesh or Baffle Filter Part Number
50210039
Duct Discharge
Vertical or Horizontal
Duct Size; Horizontal; IN
8, 3.25 x 10
Duct Size; Vertical; IN
8
Mounting Height Above Cooktop; IN
24 - 36
Voltage
120
Maximum Amperage
5
ADA Compliant
Yes, with optional remote
Warranty Parts / Labor
3 / 1
Compatible Appliances
14000005, PBD-1300B, ZRC-7036C, AK0726, AK1726, MUA008A, MUA010A, Z0F-C002, AK1716
Bluetooth Connected
No
Wi-Fi Connected
Yes
Remote Included
No
Remote Optional
Yes
Energy Star Certified
No
Alexa & Google Home Compatible
Yes
CEC Title 20 Compliant
Yes
CEC Title 24 Compliant
Yes
Primary Material
Stainless Steel
Wattage
600
Certification
UL
Nominal Width; IN
36
Net Width; IN
35.875
Net Depth; IN
22.5
Net Height; IN
11
Weight; LBS
52.000
Ceiling Height Minimum
8 ft.
Ceiling Height Maximum
12 ft.
Shipping Length; IN
41
Shipping Width; IN
17
Shipping Height; IN
30
Shipping Weight; LBS
58
Shipping Method
Small Parcel
Freight Class
150
Certification #
E127334
Clean Filter Alert
Yes
Duct Type
Vertical
GTIN
00646328009204
EAN
0646328009204
UPC
646328009204
Airflow Control Technology(TM) (ACT(TM))
LumiLight LED Lighting
Compatible with Zephyr Connect App
Professional Baffle Filters
CleanAir Function
Vertical or horizontal ducting
Optional Ductless Recirculating Kit
