PRODUCT DESCRIPTION
Specifications
Parts
3 Year
Labor
1 Year
UPC
646328009198
GTIN
00646328009198
EAN
0646328009198
Brand
Zephyr
Manufacturer
Zephyr
Category
Range Hood
Sub-Category
Under Cabinet
Vent Type
Convertible
UPC
646328009198
GTIN
00646328009198
Country of Origin
Taiwan
Model Group
AK73-A
Model Name
Tidal I Under-Cabinet
Collection
Pro Collection
Blower Included
Yes
Blower CFM w/ACT
590, 390, 290
Internal Blower 1 CFM
700
Internal Blower 1 Min. Sones
0.8
Internal Blower 1 Max Sones
6
Internal Blower 2 CFM
1300
Minimum CFM
200
Installation Type
Under Cabinet
For Outdoor Use
No
Color
Stainless Steel
Controls Type
Proximity Touch
Blower Speeds
6
Automatic Delay-Off
Yes
Clean Air Function
Yes
Lighting Type
LED
Lights Quantity
2
Watts Per Bulb
6
Lights Levels
3
Grease Filter Type
Pro baffle
Compatible Mesh or Baffle Filter Part Number
50210039
Duct Discharge
Vertical or Horizontal
Duct Size; Horizontal; IN
8, 3.25 x 10
Duct Size; Vertical; IN
8
Mounting Height Above Cooktop; IN
24 - 36
Voltage
120
Maximum Amperage
5
ADA Compliant
Yes, with optional remote
Warranty Parts / Labor
3 / 1
Compatible Appliances
14000005, ZRC-7000C, AK0720, AK1720, MUA008A, Z0F-C002, AK1710
Bluetooth Connected
No
Wi-Fi Connected
Yes
Remote Included
No
Remote Optional
Yes
Energy Star Certified
No
Alexa & Google Home Compatible
Yes
CEC Title 20 Compliant
Yes
CEC Title 24 Compliant
Yes
Primary Material
Stainless Steel
Wattage
600
Certification
UL
Nominal Width; IN
30
Net Width; IN
29.875
Net Depth; IN
22.5
Net Height; IN
11
Weight; LBS
45.000
Ceiling Height Minimum
8 ft.
Ceiling Height Maximum
12 ft.
Shipping Length; IN
41
Shipping Width; IN
17
Shipping Height; IN
30
Shipping Weight; LBS
53
Shipping Method
Small Parcel
Freight Class
150
Certification #
E127334
Clean Filter Alert
Yes
Duct Type
Vertical
