PRODUCT DESCRIPTION
Specifications
Brand
Zephyr
Manufacturer
Zephyr
Category
Range Hood
Sub-Category
Under Cabinet
Vent Type
Convertible
UPC
646328008771
GTIN
00646328008771
Country of Origin
Taiwan
Model Group
AK71-B
Model Name
Gust Under-Cabinet
Collection
Core Collection
Blower Included
Yes
Internal Blower 1 CFM
400
Internal Blower 1 Min. Sones
2
Internal Blower 1 Max Sones
5
Minimum CFM
150
Installation Type
Under Cabinet
For Outdoor Use
No
Color
Stainless Steel
Controls Type
Mechanical Slide
Blower Speeds
3
Automatic Delay-Off
No
Clean Air Function
No
Lighting Type
LED
Lights Quantity
2
Watts Per Bulb
6
Lights Levels
2
Grease Filter Type
Baffle
Compatible Mesh or Baffle Filter Part Number
Z0F-B002
Duct Discharge
Vertical or Horizontal
Duct Size; Horizontal; IN
3.25 x 10
Duct Size; Vertical; IN
7, 3.25 x 10
Mounting Height Above Cooktop; IN
24 - 32
Voltage
120
Maximum Amperage
1.7
ADA Compliant
Yes, with optional wall switch
Warranty Parts / Labor
3 / 1
Compatible Appliances
ZRC-0071, MUA006A, AK00067, Z0F-C005, AK1716
Bluetooth Connected
No
Wi-Fi Connected
No
Remote Included
No
Remote Optional
No
Energy Star Certified
No
Alexa & Google Home Compatible
No
CEC Title 20 Compliant
Yes
CEC Title 24 Compliant
Yes
Primary Material
Stainless Steel
Wattage
204
Certification
UL
Nominal Width; IN
36
Net Width; IN
35.9
Net Depth; IN
21
Net Height; IN
7.375
Weight; LBS
36.500
Ceiling Height Minimum
8 ft.
Ceiling Height Maximum
12 ft.
Shipping Length; IN
39
Shipping Width; IN
26
Shipping Height; IN
11
Shipping Weight; LBS
43
Shipping Method
Small Parcel
Freight Class
125
Certification #
E127334
Clean Filter Alert
No
Duct Type
Vertical
GTIN
00646328008771
EAN
0646328008771
UPC
646328008771
Welded and polished body
LumiLight LED Lighting
Mechanical Slide Controls
Dual-Level Lighting
Baffle filters
Vertical or horizontal ducting
Optional Ductless Recirculating Kit
