PRODUCT DESCRIPTION
Specifications
Brand
Zephyr
Manufacturer
Zephyr
Category
Range Hood
Sub-Category
Under Cabinet
Vent Type
Convertible
UPC
646328008689
GTIN
00646328008689
Country of Origin
Taiwan
Model Group
AK70-C
Model Name
Tempest I Under-Cabinet
Collection
Pro Collection
Blower Included
Yes
Blower CFM w/ACT
390, 290
Internal Blower 1 CFM
650
Internal Blower 1 Min. Sones
1
Internal Blower 1 Max Sones
6
Minimum CFM
200
Installation Type
Under Cabinet
For Outdoor Use
No
Color
Stainless Steel
Controls Type
Electronic
Blower Speeds
6
Automatic Delay-Off
Yes
Clean Air Function
Yes
Lighting Type
LED
Lights Quantity
2
Watts Per Bulb
6
Lights Levels
2
Grease Filter Type
Pro baffle
Compatible Mesh or Baffle Filter Part Number
50210039
Duct Discharge
Vertical or Horizontal
Duct Size; Horizontal; IN
8, 3.25 x 10
Duct Size; Vertical; IN
8
Mounting Height Above Cooktop; IN
26 - 36
Voltage
120
Maximum Amperage
5
ADA Compliant
Yes, with optional remote
Warranty Parts / Labor
3 / 1
Compatible Appliances
AK0726, AK1726, 14000005, PBD-1200A, ZRC-7036C, AK1716, MUA008A, Z0F-C002, MUA010A
Bluetooth Connected
No
Wi-Fi Connected
No
Remote Included
No
Remote Optional
Yes
Energy Star Certified
No
Alexa & Google Home Compatible
No
CEC Title 20 Compliant
Yes
CEC Title 24 Compliant
Yes
Primary Material
Stainless Steel
Wattage
600
Certification
UL
Nominal Width; IN
36
Net Width; IN
35.875
Net Depth; IN
22.5
Net Height; IN
11
Weight; LBS
54.500
Ceiling Height Minimum
8 ft.
Ceiling Height Maximum
12 ft.
Shipping Length; IN
41
Shipping Width; IN
17
Shipping Height; IN
30
Shipping Weight; LBS
59
Shipping Method
Small Parcel
Freight Class
150
Certification #
E127334
Clean Filter Alert
Yes
Duct Type
Vertical
GTIN
00646328008689
EAN
0646328008689
UPC
646328008689
Airflow Control Technology(TM) (ACT(TM))
Professional Baffle Filters
Welded and polished body
CleanAir Function
LumiLight LED Lighting
Optional Ductless Recirculating Kit
Optional Wireless Remote Control (14000005)
