PRODUCT DESCRIPTION
Specifications
Brand
Zephyr
Manufacturer
Zephyr
Category
Range Hood
Sub-Category
Under Cabinet
Vent Type
Convertible
UPC
646328009792
GTIN
00646328009792
Country of Origin
Taiwan
Model Group
AK12-C
Model Name
Breeze II Under-Cabinet
Collection
Core Collection
Blower Included
Yes
Internal Blower 1 CFM
400
Internal Blower 1 Min. Sones
2
Internal Blower 1 Max Sones
5
Minimum CFM
210
Installation Type
Under Cabinet
For Outdoor Use
No
Color
Stainless Steel
Controls Type
Electronic
Blower Speeds
3
Automatic Delay-Off
Yes
Clean Air Function
No
Lighting Type
LED
Lights Quantity
2
Watts Per Bulb
6
Lights Levels
2
Grease Filter Type
Mesh
Compatible Mesh or Baffle Filter Part Number
50200012
Duct Discharge
Vertical or Horizontal
Duct Size; Horizontal; IN
3.25 x 10
Duct Size; Vertical; IN
7, 3.25 x 10
Mounting Height Above Cooktop; IN
24 - 34
Voltage
120
Maximum Amperage
2
ADA Compliant
No
Warranty Parts / Labor
3 / 1
Compatible Appliances
ZRC-0012, 0AK11-20001, AK1710
Bluetooth Connected
No
Wi-Fi Connected
No
Remote Included
No
Remote Optional
No
Energy Star Certified
No
Alexa & Google Home Compatible
No
CEC Title 20 Compliant
Yes
CEC Title 24 Compliant
Yes
Primary Material
Stainless Steel
Wattage
240
Certification
UL
Nominal Width; IN
30
Net Width; IN
29.875
Net Depth; IN
20
Net Height; IN
5.5
Weight; LBS
21.5
Ceiling Height Minimum
8 ft.
Ceiling Height Maximum
12 ft.
Shipping Length; IN
34
Shipping Width; IN
9
Shipping Height; IN
25
Shipping Weight; LBS
31
Shipping Method
Small Parcel
Freight Class
125
Certification #
E127334
Clean Filter Alert
Yes
Duct Type
Vertical
GTIN
00646328009792
EAN
0646328009792
UPC
646328009792
LumiLight LED Lighting
Electronic Touch Controls
Low-profile body
Extra-wide mesh filters
Vertical or horizontal ducting
Multiple color options
Optional Ductless Recirculating Kit
