PRODUCT DESCRIPTION
Specifications
Brand
Zephyr
Manufacturer
Zephyr
Category
Range Hood
Sub-Category
Island
Vent Type
Convertible
UPC
646328004193
GTIN
00646328004193
Country of Origin
Italy
Model Group
ADL-B
Model Name
Duo Island
Collection
Designer Collection
Blower Included
No
Internal Blower 1 CFM
290
Internal Blower 1 Min. Sones
1.4
Internal Blower 1 Max Sones
3
Internal Blower 2 CFM
600
Internal Blower 2 Max Sones
6
In-Line Blower CFM
1000
External Blower CFM
1000
Installation Type
Island
For Outdoor Use
No
Color
Stainless Steel
Controls Type
Capacitive Touch
Blower Speeds
3
Automatic Delay-Off
Yes
Clean Air Function
Yes
Lighting Type
LED
Lights Quantity
2
Watts Per Bulb
8.5
Lights Levels
3
Grease Filter Type
Decorative Mesh
Compatible Mesh or Baffle Filter Part Number
50200031
Duct Discharge
Vertical
Duct Size; Horizontal; IN
N/A
Duct Size; Vertical; IN
6, 8
Mounting Height Above Cooktop; IN
24 - 36
Voltage
120
Maximum Amperage
6.5
ADA Compliant
Yes
Warranty Parts / Labor
1 / 1
Compatible Appliances
ZRC-01LL, Z1C-02LL, MUA006A, MUA008A, Z0F-01AC
Bluetooth Connected
No
Wi-Fi Connected
No
Remote Included
Yes
Remote Optional
No
Energy Star Certified
No
Alexa & Google Home Compatible
No
CEC Title 20 Compliant
Yes
Primary Material
Stainless Steel
Nominal Width; IN
42
Net Width; IN
41.9375
Net Depth; IN
23.625
Net Height; IN
29.5 - 49
Weight; LBS
105
Ceiling Height Minimum
8 ft.
Ceiling Height Maximum
10 ft.
Chimney Height in.
28
Chimney Width in.
12.93
Chimney Depth in.
11.25
Shipping Length; IN
20.87
Shipping Width; IN
46.5
Shipping Height; IN
31.5
Shipping Weight; LBS
114.6
Shipping Method
LTL
Freight Class
300
Duct Type
Vertical
GTIN
00646328004193
EAN
0646328004193
UPC
646328004193
Capacitive touch controls
CleanAir Function
Includes wireless remote control
LED light strip
Low-profile body
Quick-Lock installation system
