GET READY FOR INSTALLATION
PRODUCT DESCRIPTION
Features
HANDLELESS
Have a handleless door design? The XO GOA model accepts the panel with ease.
OPTIONAL SS ADA DOOR PANEL
If your ADA install calls for a stainless finish use the optional stainless steel overlay panel which includes two different style handles._x000D_ Product ID: XOU24ADASG
ARTICULATING HINGE
ELEGANT TRI-COLOR LIGHTING
Cool running LEDS are change with the push of a button from theater white to midnight blue or honey amber.
EASY TO STORE EASY TO FIND
Clear glass shelves extend fully while fully loaded allowing you to see everything at a glance.
34(degree) AT YOUR FINGERTIPS
with easily adjusted electronic controls you can store your favorite beverages down to a frosty 34(degree) .
ADAPTS FOR EUROPEAN PLINTH/TOE KICKS
REMOVABLE WINE DISPLAY RACK
UNIFORM TEMPERATURE
activated carbon filters and whisper quiet fans ensure the positive circulation of air for uniform temperatures.
LOW-E GLASS WITH UV BLOCKER
On all glass door units, double pane, low-e glass coated to block harmful ultraviolet light is standard for energy efficient operation and protection from damaging light.
Specifications
Origin
China
UPC
814830012412
Height
32 1/2 to 34 1/8
Width
23 7/16"
Depth
21 5/8"
Cut-Out Depth (in.)
24"
Cut-Out Height (in.)
32 1/2" to 34 1/4"
Cut-Out Width (in.)
24"
Depth (Excluding Handles)
22 7/16" includes 3/4" panel
Depth (Less Door)
19 15/16"
Depth With Door Open 90 Degrees (In)
44 11/16"
Height to Top of Door Hinge (in.)
32 1/2 to 34 1/8
Dimensions D x W x H
21 5/8" x 23 7/8" x 32 1/2 to 34 1/8"
Product Weight
125
Warranty 1 Explained
90 Day Love It Or Leave It
Warranty 2 Explained
2 year limited parts and labor warranty for the original owner
Warranty 3 Explained
5 year limited compressor parts only warranty for the original owner
ADA Compatible
Yes
Certification
CSA
Prop 65
Yes
Freight Class
92.5
Shipping Weight
125
Carton Height
37"
Carton Width
27"
Carton Depth
29"
Shipping Method
LTL
Amperage
1.2 amps
Electrical
115V-60Hz-1.2 Amps
Frequency (Hz)
60 Hz
Voltage (volts)
115V
Wattage (watts)
138 watts
Ambient Temperature
60 to 90 degrees F
Appliance Type
Beverage Center
Can Storage Capacity
118 (12oz)
Color/Finish
Panel Ready & Glass
Control Type
Intuitive Touch Digital Controls
Cooling Unit Type
Air Cooled Compressor
Cubic Foot Capacity
3.85 cu ft
Defrost Type
Automatic Defrost
Door Features
Panel Ready - UV Blocking Low-E Glass
Door Swing
Reversible
Filter Type
Activated carbon air filter
Install Type
Fully Integrated Undercounter
Installation Type
Fully Integrated Undercounter
Interior Finish Type
Molded ABS
Interior Lighting
Tri-Color LED Interior Illumination
Leveling Legs
Included
LIght Colors
Midnight Blue, Theater White, Honey Amber
Light Type
Tri-Color LED Interior Illumination
Lighting Features
Three lighting modes
Max Temperature Zone 1
50 degrees F
Min Temperature Zone 1
34 degrees F
Number of Doors
1
Number of Shelves
2
Number of Temperature Zones
1
Open Door Alarm
Yes
Operational Features
Energy Saver Mode
Power Cord Included
6' with Flat Plug
Programmed Features
Power, Lighting & Alarms
Required Plug Type
5-15P Plug Type
Returnable
No
Sabbath Mode
Yes
Shelf Material Type
Glass
Storage Features
12 Position Full Extension, Fully Loaded
Toe Kick Color
Black
Vent Location
Bottom Front
Wheels/Casters
No
Wireless Compatibility
No
Control Lighting
Backlit LCD
Controls
Electronic Touch
Location
Indoor
Refrigerant
R600a
Sound Level
37 dBA
Assembled Depth (in.)
No
Force Multiples
1
GTIN
00814830012412
EAN
0814830012412
UPC
814830012412
Seamlessly integrates with US Standard, ADA height and European cabinets
Clear glass shelves fully extend to reveal their contents and adjust to 12 different heights
Cool running interior Tri-Color LEDs dramatically illuminate your bottles while saving energy. Choose Theater White, Midnight Blue, and Honey Amber.
Articulating hinges enable use of longer panels and handleless doors
Field Reversible Panel Ready Door with UV Blocking Low-E Glass
Stores up to (118) 12oz cans from 34 to 50 F
Filtered, conditioned air is circulated to help ensure a stable, uniform temperature
Zero Clearance hinge and flat plug design ensure flush installation
LOW-E GLASS WITH UV BLOCKER
UNIFORM TEMPERATURE
EASY TO STORE EASY TO FIND
ELEGANT TRI-COLOR LIGHTING
REMOVABLE WINE DISPLAY RACK
ARTICULATING HINGE
34(degree) AT YOUR FINGERTIPS
HANDLELESS
ADAPTS FOR EUROPEAN PLINTH/TOE KICKS
OPTIONAL SS ADA DOOR PANEL
