PRODUCT DESCRIPTION
Specifications
Collection
Fabriano Collection
Origin
Italy
UPC
814830013631
Height
12"
Width
34 3/8"
Depth
22 1/2"
Cut-Out Depth (in.)
22 11/16"
Cut-Out Height (in.)
12 1/4"
Cut-Out Width (in.)
34 1/2"
Dimensions D x W x H
22 1/2" x 34-3/8" x 12"
Product Weight
38.06
Warranty 1 Explained
90 Day Love It Or Leave It
Warranty 2 Explained
2 Year Limited Material And Workmanship for the original owner
ADA Compatible
Yes
Certification
UL
Prop 65
Yes
Shipping Weight
51.48
Amperage
3.6 Amps
Electrical
120V - 60Hz - 3.6 Amps
Frequency (Hz)
60 Hz
Voltage (volts)
120 VAC
Wattage (watts)
430 watts
Appliance Type
Range Hoods
CCC Code Compliance Control
Yes
CFM @ Speed 1
160
CFM @ Speed 2
250
CFM @ Speed 3
395
CFM @ Speed 4
600
Color/Finish
Stainless
Commerical/Residential
Residential
Control Type
Backlit LED
Cooktop Lights
Twin LED Lights
Duct Size
6" Dia.
Ductless Convertible
Ducted or Convertible
Filter Type
Dishwasher Safe Pro Stainless Steel Baffles
Install Type
Insert - Liner combination
Installation Type
Insert - Liner combination
LIght Colors
White
Light Type
Twin LED Lights
Lighting Features
3 Level Lighting
Maximum Air Flow Capacity CFM)
600/395
Minimum Air Flow Capacity (CFM)
160
Mounting Height Above Cooktop
27" - 32"
Number of Light Bulbs
2
Number of Speeds
4
Returnable
No
Sones @ Speed 1
1
Sones @ Speed 2
2.5
Sones @ Speed 3
4
Sones @ Speed 4
6.5
Vent Location
Top
Vent Material
Metal
Wireless Compatibility
No
Control Lighting
Blue Backlit
Controls
Code Compliance Electronic Controls
Location
Indoor
Sound Level
1.0-6.5 Sones
Assembled Depth (in.)
No
Force Multiples
1
GTIN
00814830013631
EAN
0814830013631
UPC
814830013631
Backlit Electronic 4 Speed Control with Power Boost
CCC Code Compliance Control - permanently set blower to 395 or 600 CFM to meet local codes
High Efficiency 3000K LED lights brightly illuminate the cooktop
Dishwasher Safe Pro Style Stainless Baffle Filters for efficient filtration
5 Minute Delay Shutoff Timer
XO quality and performance for your custom built-ins
Made In Italy
2 year limited parts and labor warranty for the original owner
Combination blower and liner saves time and money
NOTE *When CCC(TM) is enabled the number of fan speeds will be reduced to maximum 3 speeds
