PRODUCT DESCRIPTION
Specifications
Ada Compliant
ADA Height and Side Reach Compliant
Prop65
Standard
Ul
Yes
Control Location
Front
Control Type
Knobs
Infinite Heat Controls
No
Cooktop Surface Color
Black
Digital Display
No
Griddle Included
N/A
Heating Element On Indicator Light
No
Hot Surface Indicator Light
No
Ignition Type
Direct Spark Ignition
Automatic Pan Detection
No
Automatic Pan Size Adjustment
No
Combinations With Oven
WOES3027L; WOES5027L; WOES5030L; WOES7027P; WOES7030P; WOS11EM4; WOS51EC0; WOS51EC7; WOS51ES4; WOS52EM4; WOS52ES4M; WOS72EC0; WOS72EC7; WOS92EC0; WOS92EC7; WOS97EC0; WOS97ES0; WOSA2EC0
Cooktop Configuration
All Burners
Installs Over Built-in Oven
Yes
Lp Convertible
Yes - Kit Included
Power Outage Compatible
Yes
Product Height
5.5625
Carton Height
12.99
Gross Weight
61.3
Carton Width
34.68
Product Depth
21.0
Cutout Depth Max
20
Cutout Width Min
28.5
Cutout Depth
20
Carton Depth
24.96
Cutout Width
29.563
Cutout Depth Min
19
Cutout Width Max
29.563
Net Weight
56.9
Product Width
30.0
Power Cord Included
Yes
Cooktop Element Style
Sealed Burner
Left Front Element-burner Power
12000 BTU
Left Front Element-burner Type
Standard
Left Rear Element-burner Power
5000 BTU
Left Rear Element-burner Type
Simmer
Number of Cooking Element-burners
4
Power Boost
No
Right Front Element-burner Power
9100 BTU
Right Front Element-burner Type
Standard
Right Rear Element-burner Power
18,000 BTU
Right Rear Element-burner Type
Power
Knob Color
Black
Knob Type
Plastic
Combination Match With Oven
WOES3027L; WOES5027L; WOES5030L; WOES7027P; WOES7030P; WOS11EM4; WOS51EC0; WOS51EC7; WOS51ES4; WOS52EM4; WOS52ES4M; WOS72EC0; WOS72EC7; WOS92EC0; WOS92EC7; WOS97EC0; WOS97ES0; WOSA2EC0
Grate Details
Cast Iron Grates; Continuous; Dishwasher Safe; Matte Finish
Number of Grates
2
Works With
No
Downdraft Vent
No
Ventilation Type
N/A
Venting
N/A
GTIN
00883049678146
EAN
0883049678146
UPC
883049678146
Easily maintain low, even heat with the 5K BTU Simmer Burner
Use your multi-purpose burners for daily cooking and searing
Meets ADA Standards for Accessible Design
Get Cooking Flexibility with a range of burner sizes and power levels
The cast-iron grates are dishwasher-safe for easy cleaning
Get more flexibility with grates that extend across the cooktop
Clean up easily with the smooth porcelain surface
Cut down on cleanup with Sealed Burners
Sear and boil quickly with the SPEEDHEAT Burner
Clean up faster with the Upswept SPILLGUARD Cooktop
Install this cooktop with a wall oven or on its own
