Thor 30 Inch Built-in Panel-ready Bottom Mount Refrigerator in Panel Ready

Name: Thor XRF3016BBP 30 Inch Built-in Panel-ready Bottom Mount Refrigerator
Brand: Thor
SKU: XRF3016BBP
Price: 7799.00 USD
Availability: InStock

SKU: XRF3016BBP

0 Questions & 0 Answers

Type: Built-In
Style: Bottom Freezer
Energy Star Rated: yes
Wi-Fi Connected: No
Sabbath Mode: Yes
ADA Compliant: No
Freezer Capacity: 4.5 cu. ft.
Icemaker: Yes
Dispenser: Yes
Total Capacity: 16.10 cu. ft.
Refrigerator Capacity: 11.6 cu. ft.
Number of Shelves: 3

Thor |Authorized Dealer

Pre-Order

$7,799.00

$10,149.00 Save$2,350.00

$194.98

)

Estimates for:

Protect Your Item

2 Year $215.99

3 Year $335.99

4 Year $389.99

5 Year $489.99

Decline

30-Days Free Returns or Exchanges

PRODUCT DESCRIPTION

THOR Kitchen offers the power and performance of a premium professional appliance at a practical price. THOR S 30-inch panel-ready Built-In Bottom Freezer Refrigerator seamlessly integrates, flush with your cabinetry, for a fully personalized kitchen. This 30-inch refrigerator (XRF3016BBP) has reversible doors, allowing you to combine two units for one massive 60-inch unit. Are you going for small but mighty, or large and in charge? The choice is yours. #IgniteYourCulinaryCreativity

technical details

9 items

Total Capacity (cu. ft.)

16.1

Refrigerator Capacity (cu. ft.)

11.6

Freezer Capacity (cu. ft.)

4.5

Amperage or Current (A)

Volts (V)

120

Frequency (Hz)

Plug Type

3-Prong Grounding Plug

Power Cord Length (in.)

86.6

Energy consumption

551 kwh/yr

general properties

12 items

Number Of Doors

Number Of Shelves

Number Of Freezer Baskets

Number of Door Bins

3 (2+1 Gallon Bins)

Adjustable Racks & Removable Shelves

Shelf Material

Glass

Reversible Door Swing

Yes

Soft Closing Drawer Feature

Yes

Water Filter

Yes

Lighting

LED

Freezer Defrost Process

Automated Defrosting

Certification

Energy Star Rated / ETL Certified

dimensions

4 items

Product Dimensions (HxWxD) (in.)

83-9/16 x 29-3/4 x 23-5/16

Package (HxWxD) (in.)

90-9/16 x 32-5/16 x 26-3/8

Product Height To Top Of Refrigerator (in.)

83-1/2

Cutout Dimensions (HxWxD) (in.)

84 x 30 x 25

stainless steel door panels with handle set for xrf3016bbp (dkxrf3016bbp-ss)

3 items

Fridge Door Dimensions (WxHxD)

29-3/4 x 51-1/16 x 3/4

Weight (lbs.)

23.8

Freezer Door Dimensions (WxHxD)

29-3/4 x 28-11/16 x 3/4

weight

2 items

Product Weight (lbs)

342 lbs

Package Weight (lbs

386 lbs

#

4 items

The water pressure of the cold water supply must be between 25-80 psi. (1.7-5.5 Bar)

If the water pressure exceeds 80 psi (5.5 Bar), install a pressure limiting device or water impact protector to the water in valve.

Do not install or operate the appliance if the water pressure exceeds 120 psi. (8.3 Bar)

If there are issues with the water pressure, contact a qualified plumber.

Documents

Specification Sheet

PDF

Use and Care Manual

PDF

Installation Manual

PDF
