PRODUCT DESCRIPTION
Specifications
Nominal Height
42.0" (107 cm)
Height of Cabinet
42.0" (107 cm)
Nominal Width
20.0" (51 cm)
Width
19.5" (50 cm)
Nominal Depth
24.0" (61 cm)
Depth
23.5" (60 cm)
Depth with Handle
25.75" (65 cm)
Depth with door at 90(degree)
43.25" (110 cm)
Door
White
Cabinet
White
US Electrical Safety
CSA
Canadian Electrical Safety
CSA-C
Voltage/Frequency
115 V AC/60 Hz
Weight
130.0 lbs. (59 kg)
Parts & Labor Warranty
1 Year
UPC
761101058269
Ignition
Spark
LP Convertible
Yes
Oven Capacity
2.3 cu.ft
Cooktop Surface
Metal
Burner Type
Sealed
Number of Burners
4
Burner #1 BTU
12000.0
Burner #2 BTU
9500.0
Burner #3 BTU
9500.0
Burner #4 BTU
5000.0
Burner Controls
Dial
Oven Controls
Dial
Backguard
Yes
Cleaning Type
Manual
Oven Rack Qty
2
Oven Interior Height
15.25" (39 cm)
Oven Interior Width
14.5" (37 cm)
Oven Interior Depth
17.5" (44 cm)
Broiler Location
Below Oven
GTIN
00761101058269
EAN
0761101058269
UPC
761101058269
Four sealed burners with removable cast iron tops ensure safer, cleaner cooking
Unit is set for natural gas but can be converted aftermarket with the included LP kit
Front left burner features 12,500 BTU output for powerful cooking
Two right burners operate at 9,500 BTU to handle most heating needs
Rear left burner reaches maximum of 5,000 BTUs to allow more precise heating of sensitive items
Two sets of grates are removable for easy cleaning, with solid construction to support large pots and pans
Drop-down lower compartment offers the ideal conditions for broiling
Safety knobs help prevent accidents from turning on the oven or burners
Added safety with spark ignition system
Sliding racks will stay in your oven with special brake mechanism
Two-piece broiler pan with lid included with each range
Upfront controls and easy-to-operate knobs offer easier accessibility
Solid backing prevents stovetop contents from splashing up or boiling over and staining walls
Standard 3-pronged 115V cord included for the electronic ignition
Included for user installation to help prevent accidents
