GET READY FOR INSTALLATION
PRODUCT DESCRIPTION
Specifications
Height of Cabinet
73.88" (188 cm)
Height to Hinge Cap
74.38" (189 cm)
Width
23.63" (60 cm)
Width with Door Open
24.63" (63 cm)
Depth
25.25" (64 cm)
Depth with Handle
27.25" (69 cm)
Depth with door at 90(degree)
47.0" (119 cm)
Capacity
10.8 cu.ft. (306 L)
Defrost Type
Frost-Free/Automatic
Door
Stainless Steel
Cabinet
Platinum
US Electrical Safety
ETL
Canadian Electrical Safety
ETL-C
Energy Usage/Year
487.2kWh/year
Amps
1.5
Voltage/Frequency
115 V AC/60 Hz
Weight
175.0 lbs. (79 kg)
Shipping Weight
220.0 lbs. (100 kg)
Parts & Labor Warranty
1 Year
Compressor Warranty
5 Years
UPC
761101054827
Door Swing
RHD
Reversible
Factory Reversible
Adjustable Shelves
Yes
Interior Drawers
Yes
Drawer Qty
4
Crisper Qty
2
Crisper Finish
Transparent
Crisper Cover
Glass
Wine Bottle Shelving
Yes
Interior Light
Yes
Refrigerator - Interior Height
38.5" (98 cm)
Refrigerator - Interior Width
19.25" (49 cm)
Refrigerator - Interior Depth
17.5" (44 cm)
Refrigerator - Capacity
7.8 cu.ft
Refrigerator - Shelf Type
Glass and Scalloped
Refrigerator - Shelf Qty
3
Refrigerator - Full Door Shelves
3
Refrigerator - Temperature Range
34 to 46 F
Freezer - Interior Height
24.0" (61 cm)
Freezer - Interior Width
16.5" (42 cm)
Freezer - Interior Depth
13.0" (33 cm)
Freezer - Capacity
3.0 cu.ft
Thermostat Type
Digital
Fan Type
Interior and Exterior
Refrigerant Type
R134a
Refrigerant Amount
5.11 oz.
High Side PSI
215.0
Low Side PSI
36.0
Level Legs
2
Condensor Location
Rear of Unit
Freezer - Temperature Range
-6 to 6 F
Compressor Step Height
8.0" (20 cm)
Compressor Step Width
16.5" (42 cm)
Compressor Step Depth
5.0" (13 cm)
Front-breathing design allows fully integrated installation
Professional look in high quality stainless steel, with a unique curve to add a modern touch to any kitchen
Convenient design keeps all refrigerated storage at eye level for easier use
Separate digital controls located on the door let you adjust the refrigerator and freezer sections, with a digital display for added convenience
Innovative sensor technology allows the unit to adjust to your habits, reading your patterns to manage the temperature based on the frequency of door openings and grocery loading
Large icemaker in freezer ensures a steady supply of ice cubes
Spill-proof safety glass for durable and easy-to-clean storage that can be rearranged as needed
Three door racks can be adjusted in height to accommodate a variety of sizes
Lower door rack is ideal for storing tall condiments
Store bottles safely on an adjustable scalloped steel rack
Large crisper drawer allows you to ensure the optimum storage of fruits and vegetables
Slide-out drawer allows you to store meats and other deli items at a slightly colder temperature for long-lasting freshness
Removable container with a silicone lid and air-tight seal offers a convenient way to store smaller food items with a strong odor, such as blue-vein cheeses or onions
Automatically illuminates when you open the door
Unique freezer design keeps the cold inside, even when the door is opened
Audible and visual alarm will alert if the doors have been left ajar for over 2 minutes
Audible and visual alarms will alert if the temperature in the refrigerator or freezer compartment is too high
All alarms are both audible and visual, with lamps in the control panel that will illuminate when the alarm is sounded
Frost-free freezer section and automatic defrost refrigerator offer low maintenance operation
Allows you to rapidly cool the refrigerator or freezer section, ideal for bringing newly loaded groceries to a safer storage temperature
Temperature controls include a locking function to prevent accidental setting changes
Unit ships RHD unless ordered reversed in our factory. The doors are not user-reversible
Environmentally friendly design without ozone-damaging chemicals
