GET READY FOR INSTALLATION
PRODUCT DESCRIPTION
Specifications
Nominal Height
34.0" (86 cm)
Height of Cabinet
33.5" (85 cm)
Nominal Width
24.0" (61 cm)
Width
23.63" (60 cm)
Nominal Depth
24.0" (61 cm)
Depth
23.5" (60 cm)
Depth with door at 90(degree)
45.13" (115 cm)
Capacity
5.1 cu.ft. (144 L)
Defrost Type
Cycle
Door
Panel-Ready
Cabinet
White
US Electrical Safety
ETL
Canadian Electrical Safety
ETL-C
Amps
1.4
Voltage/Frequency
115 V AC/60 Hz
Weight
100.0 lbs. (45 kg)
Parts & Labor Warranty
1 Year
Compressor Warranty
5 Years
UPC
761101068848
Door Swing
RHD
Reversible
Factory Reversible
Adjustable Shelves
Yes
Crisper Qty
1
Crisper Finish
Transparent
Crisper Cover
Glass
Interior Light
Yes
Refrigerator - Interior Height
19.5" (50 cm)
Refrigerator - Interior Width
20.5" (52 cm)
Refrigerator - Interior Depth
17.0" (43 cm)
Refrigerator - Shelf Type
Wire
Refrigerator - Shelf Qty
2
Refrigerator - Full Door Shelves
3
Freezer - Interior Height
5.0" (13 cm)
Freezer - Interior Width
19.0" (48 cm)
Freezer - Interior Depth
11.5" (29 cm)
Thermostat Type
Dial
Fan Type
Exterior
Refrigerant Type
R600a
Refrigerant Amount
0.92 oz.
High Side PSI
180.0
Low Side PSI
80.0
Level Legs
4
Compressor Step Height
7.0" (18 cm)
Compressor Step Width
20.5" (52 cm)
Compressor Step Depth
5.0" (13 cm)
GTIN
00761101068848
EAN
0761101068848
UPC
761101068848
Less than 24 inches wide to fit tight spaces
Keyed lock offers added security
Front-breathing design lets you make the best use of space by installing your appliance under the counter
Allows the unit to be used freestanding
This system utilizes user-friendly automatic defrost operation in the fresh food section and efficient manual defrost operation in the freezer compartment
Our unique and efficient design separately cools the refrigerator while maintaining a lower temperature in the freezer compartment by utilizing two evaporators
Rearrange the refrigerator space to fit any sized item or remove shelves for simple cleanup
Get the longest life and best taste out of produce by storing greens in lower slide drawer
Keep tall bottles and condiments right on the door for convenient access
Automatically illuminates when the door is opened
Dial thermostat located inside for easy temperature management
Environmentally friendly design does not contain ozone-damaging chemicals
Environmentally friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations
