GET READY FOR INSTALLATION
PRODUCT DESCRIPTION
Specifications
Nominal Height
34.0" (86 cm)
Height of Cabinet
33.5" (85 cm)
Nominal Width
24.0" (61 cm)
Width
23.63" (60 cm)
Nominal Depth
24.0" (61 cm)
Depth
23.5" (60 cm)
Depth with Handle
25.13" (64 cm)
Depth with door at 90(degree)
46.25" (117 cm)
Capacity
5.1 cu.ft. (144 L)
Defrost Type
Cycle
Door
White
Cabinet
White
US Electrical Safety
ETL
Canadian Electrical Safety
ETL-C
Amps
1.4
Weight
100.0 lbs. (45 kg)
Parts & Labor Warranty
1 Year
Compressor Warranty
5 Years
UPC
761101068800
Door Swing
RHD
Reversible
Yes
Adjustable Shelves
Yes
Crisper Qty
1
Crisper Finish
Transparent
Crisper Cover
Glass
Interior Light
Yes
Refrigerator - Interior Height
19.5" (50 cm)
Refrigerator - Interior Width
20.5" (52 cm)
Refrigerator - Interior Depth
17.0" (43 cm)
Refrigerator - Shelf Type
Wire
Refrigerator - Shelf Qty
2
Refrigerator - Full Door Shelves
3
Freezer - Interior Height
5.0" (13 cm)
Freezer - Interior Width
19.0" (48 cm)
Freezer - Interior Depth
11.5" (29 cm)
Thermostat Type
Dial
Fan Type
Exterior
Refrigerant Type
R600a
Refrigerant Amount
0.92 oz.
High Side PSI
180.0
Low Side PSI
80.0
Level Legs
4
Compressor Step Height
7.0" (18 cm)
Compressor Step Width
20.5" (52 cm)
Compressor Step Depth
5.0" (13 cm)
GTIN
00761101068800
EAN
0761101068800
UPC
761101068800
Make the best use of space by installing your refrigerator under the counter and flush with other cabinets
This system utilizes user-friendly automatic defrost operation in the fresh food section and efficient manual defrost operation in the freezer compartment
Our unique and efficient design separately cools the refrigerator while maintaining a lower temperature in the freezer compartment by utilizing two evaporators
Keyed lock offers added security
Dial thermostat located inside for easy temperature management
Automatically illuminates when you open the door
Rearrange your refrigerator space to accommodate all shapes and sizes or remove shelves for a simple clean-up
Get the longest life and best taste out of produce by storing it in a convenient slide drawer
Store large bottles right on the door for easy access
User-reversible door swing for added flexibility
Cold wall design with hidden evaporator and seamless interior
Environmentally friendly design without ozone-damaging chemicals
Environmentally friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations
