Summit 15" Undercounter Clear Ice Maker, 22 lbs. Storage Capacity in Panel Ready

SKU: BIM26H34IF
  • Width: 14.88"
  • Height: 31.75"
  • Depth: 21.38"
  • Energy Star Rated: no
  • Wi-Fi Connected: No
  • ADA Compliant: Yes
  • Defrost: Manual
  • Type: Freestanding
Summit | Authorized Dealer
Pre-Order

Estimates for:

Protect Your Item

$2,285.00
EARN 2,285 POINTS (sign in / sign up for free)

Protect Your Item

PRODUCT DESCRIPTION

Summit combines convenience and luxury to craft the BIM26H34IF - an undercounter icemaker finished in complete 304-grade stainless steel. Sized at just under 15" wide, the BIM26H34IF features a front-breathing design for built-in installation but also has a fully finished cabinet to allow freestanding use. With a height of 34", Summit designed this icemaker to be compatible with standard counters. This unit can be lowered just under 32" to fit ADA-compliant spaces. A smaller kickplate is included for a streamlined and cohesive look. This model features a panel-ready door with an integrated stainless steel frame that lets you install your own overlay panel and handle to match or complement surrounding cabinetry (recommended panel dimensions: 27 9/16" H x 14 13/16" W at 3/4" thick). The sealed back design allows more flush installation. An optional water filter is included and designed to be mounted in the rear. A look inside the BIM26H34IF shows it can produce 25 lbs of crescent-shaped ice daily. The static manual defrost cooling system allows ice to stay solid longer. No drain or pump is required, offering more placement flexibility. For optimal convenience, Summit has pre-installed the connection hose. Plus, this icemaker comes with a removable ice bucket, ice scoop, and a holder for the scoop. With its customizable exterior, stainless steel cabinet, and low maintenance design, the BIM26H34IF drain-free icemaker is a great way to finish any undercounter kitchen space and allows you to maintain an entire supply of ice with less waste.

Specifications

Nominal Height

34.0" (86 cm)

Height of Cabinet

34.0" (86 cm)

Nominal Width

15.0" (38 cm)

Width

14.88" (38 cm)

Nominal Depth

21.0" (53 cm)

Depth

20.13" (51 cm)

Depth with door at 90(degree)

34.38" (87 cm)

Defrost Type

Manual

Door

Panel-Ready

Cabinet

Stainless Steel

US Electrical Safety

ETL

Canadian Electrical Safety

ETL-C

Amps

1.9

Voltage/Frequency

115 V AC/60 Hz

Weight

65.0 lbs. (29 kg)

Parts & Labor Warranty

1 Year

Compressor Warranty

5 Years

UPC

761101108438

Door Swing

RHD

Reversible

Yes

Height Adjustable

Yes

Daily Ice Production

25.0 lbs. (11 kg)

Ice Storage Capacity

22.0 lbs. (10 kg)

Ice Shape

Crescent

Size of Cube

1/2" x 3/4" x 2 3/8"

Number of Ice Cube Sizes

1

Refrigerant Type

R600a

Refrigerant Amount

1.58 oz.

High Side PSI

120.0

Low Side PSI

55.0

Interior Height

15.88" (40 cm)

Interior Width

11.88" (30 cm)

Interior Depth

12.38" (31 cm)

Level Legs

4

GTIN

00761101108438

EAN

0761101108438

UPC

761101108438

No drain is required for more flexibility in placing the icemaker indoors or outside

Produces and stores more than 20 lbs of ice per day cycle

Convenient design allows more flexibility in positioning the unit

Static cooling system helps to keep ice frozen for longer periods of time compared to other systems

304-grade stainless steel allows the icemaker to be used freestanding

Make the best use of space by installing your ice maker under the counter

User-reversible door swing for flexible placement

Space-saving design with easier cleanability

Operates with a standard 1/4 OD water supply line

Water filter is included for optional use

Large ice scoop and holder included for your convenience

Crescent-shaped ice provides a harder and longer-lasting ice

Users can remove the ice bucket for fast and easy cleaning

Ice stays solid longer in this cold-protected bin

Environmentally friendly design without ozone-damaging chemicals

Complies with California Health and Safety Code 116876 lead leaching requirements per NSF NSF/ANSI/CAN 61-2022 standard, as well as with lead content requirements for lead free plumbing as defined by California, Vermont, Maryland, and Louisiana state laws and the U.S. Safe Drinking Water Act Section 1417(d) per NSF/ANSI/CAN 372-2022 standard
