GET READY FOR INSTALLATION
PRODUCT DESCRIPTION
Specifications
Height of Cabinet
34.0" (86 cm)
Width
18.5" (47 cm)
Width with Door Open
19.0" (48 cm)
Depth
19.0" (48 cm)
Depth with Handle
20.75" (53 cm)
Depth with door at 90(degree)
36.0" (91 cm)
Capacity
3.0 cu.ft. (85 L)
Defrost Type
Automatic
Door
Glass
Cabinet
White
US Electrical Safety
ETL
Canadian Electrical Safety
ETL-C
Amps
0.6
Voltage/Frequency
115 V AC/60 Hz
Weight
85.0 lbs. (39 kg)
Shipping Weight
95.0 lbs. (43 kg)
Parts & Labor Warranty
2 Years
Compressor Warranty
5 Years
UPC
761101065755
Door Swing
RHD
Reversible
Factory Reversible
Shelf Type
Wire
Shelf Qty
4
Adjustable Shelves
Yes
Thermostat Type
Digital
Fan Type
Interior
Refrigerant Type
R600a
Refrigerant Amount
1.06oz.
Interior Light
Yes
Temperature Range
2 to 10 C
Interior Height
28.38" (72 cm)
Interior Width
15.25" (39 cm)
Interior Depth
11.75" (30 cm)
Compressor Step Height
8.0" (20 cm)
Compressor Step Width
15.25" (39 cm)
Compressor Step Depth
3.75" (10 cm)
Extra key Extra keys available for purchase
LHD - Left hand door swing Door reversal to left hand swing
KAL-Keyless Access Lock Battery-powered self
locking keypad lock installed towards the top of this refrigerator
Purpose-built design: Designed and purpose-built to meet the demanding needs of scientific, life science, laboratory, and medical cold storage applications
+/-1 C Variation: The published temperature variation is derived from the maximum deviation of an NTC sensor in a 1 oz. vial located nearest the chamber geometric center during a 24 hour test period
Adjustable temperature: Intuitive controls let you adjust the interior temperature between +2 to +10 C
Digital data logger (DDL) included: Accucold DL2B data logger is NIST calibrated in our ISO/IEC 17025:2017 laboratory, with user-set logging intervals, a large LCD readout of the current and high/low temperature, and virtually unlimited storage through internal memory and a convenient USB drive; for additional information on this logger's features, view the DL2BKit on our webiste
Antimicrobial silver ion-coated handle: Powder-coated handle with naturally occurring silver ions to help reduce germ spread
Temperature alarm: Visual and audible alarms alert if the interior temperature rises or falls out of set range
Remote alarm contacts: Electronic controller is equipped with a volt-free contact for alarm forwarding to an external remote system (contacts located in the external rear of the unit)
Automatic defrost with adjustable cycle defrost: Adjustable cycle defrost operation ensures the unit avoid temperature spikes and ice buildup
Access port: Includes a pre-installed 1/2" probe hole in the right interior wall to allow easier connection to user-provided monitoring equipment
Open door alarm: Alarm will sound if the door is left ajar for over 4 minutes (adjustable from 1-99 minutes)
Audible power failure alarm: Battery-powered alarm sounds if the power connection is interrupted
Sensor failure alarm: Audible and visual alarm warns if the sensor is disrupted
Password protection: Control panel requires password entry to adjust the parameters beyond the set point
Microprocessor control panel: Digital controls with a large LED readout in Celsius or Fahrenheit for intuitive temperature management
Resettable min/max display: Control panel provides a readout of the low and high temperatures in 15 minute increments
Factory-installed lock: Keyed lock conveniently located towards the top of the door for added security (2 keys included)
Adjustable plastic-coated wire shelves for improved circulation: Shelves can be positioned with a front lip for small storage items or reversed to a flat position to better hold larger items, with multiple shelf positions spaced at 1/2" to accommodate virtually any size
Hospital grade cord with 'green dot' plug: Secure three-pronged cord for added unit safety
Durable interior: Walls are constructed from white powder coated metal for added strength and improved temperature retention
Interior light: Energy efficient LED lighting with internal on/off switch
Double pane tempered glass door: Provides a full display of stored contents
Self-closing door: Helps to ensure stored contents aren't overexposed to ambient temperature
Magnetic door gasket: Quality door gaskets ensure a tight seal for energy savings and improved performance
Extended warranty: 2 years parts and labor/5 years compressor
Eco-Friendly: Using environmentally friendly hydrocarbons refrigerants for a greener footprint
Usage stickers: Ships with removable warning stickers for "DO NOT UNPLUG," "DO NOT ADJUST TEMPERATURE," and "DO NOT STORE PERSONAL ITEMS"
Additional choices: Solid and glass door choices available from 1 to 15 cu.ft. Browse the Med-Lab series for more information
Versatile design: Compatible with Pyxis(R), Omnicell(R), and AcuDose RX(R)
100% CFC free: Environmentally friendly design without ozone-damaging chemicals
CARB Compliant: Environmentally friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations
