Summit 23" Freestanding Upright Freezer, 3.7 cu. ft. Capacity

SKU: ADFD243CSS
  • Style: Upright
  • Type: Freestanding
  • Width: 23.38"
  • Height: 31.88"
  • Depth: 23.88"
  • Wi-Fi Connected: No
  • ADA Compliant: Yes
  • Total Capacity: 3.70 cu. ft.
  • Defrost: Frost-Free
  • Sabbath Mode: Yes
Summit |Authorized Dealer
In Stock
$3,515.00
đź›’ extra $736.00 off in cart
Sign in / Sign up to earn 2,779 points (
$69.48
)

Estimates for:

Protect Your Item

PRODUCT DESCRIPTION

Summit manufactures an extensive selection of drawer refrigeration designed to bring elegant style and modern convenience to any undercounter space, with ADA compliant choices designed for indoor and outdoor installation. Sized at just under 24" wide and 32" high, model ADFD243CSS is a 2-drawer freezer perfectly designed for built-in or freestanding installation in ADA compliant settings with lower counter height. The cabinet and drawers are constructed from weatherproof stainless steel for safe use in outdoor kitchens, with a sealed back to protect all components from the elements. A stainless steel kickplate and sleek horizontally mounted handles complete the stylish look. The drawer fronts can also accept user-provided overlay panels to create a custom look that blends into existing cabinetry designs (panel dimensions: 23.43" W x 14.1" H at 3/4" thick). Inside, the ADFD243CSS has a generous 3.7 cu.ft. capacity to accommodate your storage needs. Frost-free operation ensures minimal user maintenance, with fan-forced cooling to evenly distribute the temperature. A digital thermostat, located atop the upper drawer, makes it easy to manage the temperature, with an LED display that can be read in Celsius or Fahrenheit. Two adjustable, removable dividers allow you to separate the drawer compartments into two or four zones to easily accommodate a variety of sizes. A full-width sliding removable chrome basket offers added storage convenience, while white LED lighting makes it easy to view stored contents. A child lock will disable the digital controls after two minutes of inactivity to prevent accidental adjustments. Additional features include audible alarms for high-temperature fluctuations and open drawer alerts, a temporary memory function to recover all settings in the event of power loss, and sabbath mode to disable certain electrical features during periods of religious observance. The ADFD243CSS is ETL-S listed to NSF-7 commercial settings and also meets all residential standards for home use. We also offer a matching refrigerator drawer (model ADRD241CSS) and this same unit as a 2-zone refrigerator-freezer drawer (model ADRF244CSS). Browse the full Summit line to explore our extensive series of 15", 18", and 24" wide refrigerator drawers.

Specifications

overview

Nominal Height
32.0" (81 cm)
Height of Cabinet
31.88" (81 cm)
Nominal Width
24.0" (61 cm)
Width
23.38" (59 cm)
Nominal Depth
23.0" (58 cm)
Depth
22.5" (57 cm)
Depth with Handle
23.88" (61 cm)
Depth with door at 90(degree)
34.25" (87 cm)
Capacity
3.7 cu.ft. (105 L)
Defrost Type
Frost-Free
Door
Stainless Steel/Panel-Ready
Cabinet
Stainless Steel
US Electrical Safety
ETL
Canadian Electrical Safety
ETL-C
Sanitation
ETL-S
Energy Usage/Year
395.0kWh/year
Amps
1.5
Voltage/Frequency
115 V AC/60 Hz
Weight
136.0 lbs. (62 kg)
Parts & Labor Warranty
1 Year
Compressor Warranty
5 Years
UPC
761101088235

freezer

Door Swing
Drawer
Thermostat Type
Digital
Interior Light
Yes
Fan Type
Interior and Exterior
Refrigerant Type
R600a
Refrigerant Amount
1.31 oz.
High Side PSI
270.0
Low Side PSI
105.0
Level Legs
4
Interior Drawers
Yes
Drawers Qty
2
Interior Height - Drawer 1
8.0" (20 cm)
Interior Width - Drawer 1
17.0" (43 cm)
Interior Depth - Drawer 1
14.5" (37 cm)
Interior Height - Drawer 2
8.0" (20 cm)
Interior Width - Drawer 2
17.0" (43 cm)
Interior Depth - Drawer 2
14.5" (37 cm)
Compressor Step Height
4.0" (10 cm)
Compressor Step Width
17.0" (43 cm)
Compressor Step Depth
3.5" (9 cm)
Temperature Range
-11(degree)F to 11(degree)F
Sabbath Mode
Yes
Sound Level
33.8 dB

GS1

GTIN
00761101088235
EAN
0761101088235
UPC
761101088235
