Summit 23" Freestanding Upright Freezer, 3.7 cu. ft. Capacity

SKU: ADFD243
  • Style: Upright
  • Width: 23.38"
  • Height: 31.88"
  • Depth: 23.88"
  • Energy Star Rated: no
  • Wi-Fi Connected: No
  • ADA Compliant: Yes
  • Total Capacity: 3.71 cu. ft.
  • Defrost: Frost-Free
  • Sabbath Mode: Yes
  • Type: Freestanding
Summit | Authorized Dealer
Pre-Order

Estimates for:

Protect Your Item

$2,755.00
EARN 2,755 POINTS (sign in / sign up for free)

Protect Your Item

PRODUCT DESCRIPTION

Summit manufactures an extensive selection of drawer refrigeration designed to bring elegant style and modern convenience to any undercounter space, with ADA compliant choices designed for indoor and outdoor installation. Sized at just under 24" wide and 32" high, model ADFD243 is a 2-drawer freezer perfectly designed for built-in or freestanding installation in ADA compliant settings with lower counter height. The fully finished black cabinet and stainless steel drawer fronts feature weatherproof construction for safe use in outdoor kitchens, with a sealed back to protect all components from the elements. Sleek horizontally mounted handles complete the stylish look. The drawer fronts can also accept user-provided overlay panels to create a custom look that blends into existing cabinetry designs (panel dimensions: 23.43" W x 14.1" H at 3/4" thick). Inside, the ADFD243 has a generous 3.7 cu.ft. capacity to accommodate your storage needs. Frost-free operation ensures minimal user maintenance, with fan-forced cooling to evenly distribute the temperature. A digital thermostat, located atop the upper drawer, makes it easy to manage the temperature, with an LED display that can be read in Celsius or Fahrenheit. Two adjustable, removable dividers allow you to separate the drawer compartments into two or four zones to easily accommodate a variety of sizes. A full-width sliding removable chrome basket offers added storage convenience, while white LED lighting makes it easy to view stored contents. A child lock will disable the digital controls after two minutes of inactivity to prevent accidental adjustments. Additional features include audible alarms for high-temperature fluctuations and open drawer alerts, a temporary memory function to recover all settings in the event of power loss, and sabbath mode to disable certain electrical features during periods of religious observance. The ADFD243 is ETL-S listed to NSF-7 commercial settings and also meets all residential standards for home use. We also offer a matching refrigerator drawer (model ADRD241) and this same unit as a 2-zone refrigerator-freezer drawer (model ADRF244). Browse the full Summit line to explore our extensive series of 15", 18", and 24" wide refrigerator drawers.

Specifications

Nominal Height

32.0" (81 cm)

Height of Cabinet

31.88" (81 cm)

Nominal Width

24.0" (61 cm)

Width

23.38" (59 cm)

Nominal Depth

23.0" (58 cm)

Depth

22.5" (57 cm)

Depth with Handle

23.88" (61 cm)

Depth with door at 90(degree)

34.25" (87 cm)

Capacity

3.71 cu.ft. (105 L)

Defrost Type

Frost-Free

Door

Stainless Steel/Panel-Ready

Cabinet

Black

US Electrical Safety

ETL

Canadian Electrical Safety

ETL-C

Sanitation

ETL-S

Energy Usage/Year

395.0kWh/year

Amps

1.5

Voltage/Frequency

115 V AC/60 Hz

Weight

106.0 lbs. (48 kg)

Parts & Labor Warranty

1 Year

Compressor Warranty

5 Years

UPC

761101079561

Thermostat Type

Digital

Interior Light

Yes

Fan Type

Interior and Exterior

Refrigerant Type

R600a

Refrigerant Amount

1.31 oz.

High Side PSI

270.0

Low Side PSI

105.0

Level Legs

4

Interior Drawers

Yes

Drawers Qty

2

Interior Height - Drawer 1

8.0" (20 cm)

Interior Width - Drawer 1

17.0" (43 cm)

Interior Depth - Drawer 1

14.5" (37 cm)

Interior Height - Drawer 2

8.0" (20 cm)

Interior Width - Drawer 2

17.0" (43 cm)

Interior Depth - Drawer 2

14.5" (37 cm)

Compressor Step Height

4.0" (10 cm)

Compressor Step Width

17.0" (43 cm)

Compressor Step Depth

3.5" (9 cm)

Temperature Range

-11(degree)F to 11(degree)F

Sabbath Mode

Yes

Sound Level

33.8 dB

GTIN

00761101079561

EAN

0761101079561

UPC

761101079561

Constructed and approved for outdoor installation (as well as use indoors) with a fully sealed cooling system and weatherproof exterior

Drawer interiors and exteriors are fully constructed from 304 grade stainless steel for weatherproof durability and elegant style

Sleek stainless steel handles add an elegant touch to any setting

No-frost operation for minimum user maintenance

Electronic controls located on the top drawer ensure intuitive temperature management, with an external readout that can switch from Celsius to Fahrenheit at the touch of a button

Elegant LED lighting in a gentle white hue illuminates the top drawer for an easy view of the interior

Fan-forced cooling ensures even temperature distribution from top to bottom

Two adjustable dividers make it easier to organize the drawer interiors

Removable chrome basket included for added storage convenience

Audible alarm will sound if either drawer is left open longer than one minute

Optional setting lets you disable the lighting and alarm for up to 48 hours during periods of observance

Allows you to lower the temperature and continuously run the compressor for short periods of time, ideal for recently loaded groceries

Disables digital controls after two minutes of activity for added safety

Unit will restore the most recent temperature settings after losing power

Design allows you to plug the unit in flush against the wall socket with no need to add extra depth

Space-saving design with no exposed coils for easier cleanability and added protection from the elements

Allows the freezer to be used as a freestanding model

Included and recommended for user-installation to reduce the risk of tipping

ETL-S listed to NSF-7 standards to allow use in commercial establishments

Pair with the ADRD241 refrigerator to create a complete 2-drawer undercounter set

Environmentally friendly design without ozone-damaging chemicals

Eco-friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations
