PRODUCT DESCRIPTION
5 "full-power" cook zones
Front-left - Bridge zone: 1,800W 7 1/2" (180mm) Booster:
2,500W
Back-left - Bridge zone: 1,800W 7 1/2" (180mm) Booster:
2,500W
Central: 2,800W 11 8/11" (300mm) Booster: 5,000W
Back-right - Bridge zone: 1,800W 7 1/2" (180mm) Booster:
2,500W
Front-right - Bridge zone: 1,800W 7 1/2" 180mm) Booster:
2,500W
Slider touch controls setting
2 bridge areas: extended cooking zone (front-left+back-left
position and frontright + back-right)
9 power levels for each zone
Simmering function
Melting/low-temperature cooking function
Indication of the minimum pan diameter
Residual heat indicator for each zone
Protection against accidental start-up
Automatic safety cut-out
Individual timer for each zone
Child safety lock
Voltage rating: 208/240V - 60Hz
Connected load (nominal power): 11.10 kW - 46 Amps
Electrical - single phase 3 or 4-wire cable required,
60 Hz, fused on both sides of line with ground
Specifications
Product family
Cooktop
Dimensions
36"
Type
Induction
Installation
Ultra-low profile
Power supply
Electric
EAN code
8017709207281
Color
Black
Finishing
Glass
Aesthetics
Universal
Material
Glass
Glass
Ceramic
Control setting type
Touch controls
Controls position
Front
Slider
Yes
Glass edge
Beveled
Silkscreen color
Gray
Cooking zones
5
Cooking zones with Booster
5
No. of Flexible zones
2
Main on/off switch
Yes
Power levels
9
Flexible zone
Bridge
Pause option
Yes
End cooking timer
5
End-of-cooking acoustic alarm
Yes
Residual time indicator
Yes
Child safety lock
Yes
Twin-zone option
Yes
Simmer
Yes
Automatic simmer
Yes
Quick level selection
Yes
Zone 1 - Type
Induction - single
Zone 2 - Type
Induction - single
Zone 3 - Type
Induction - single
Zone 4 - Type
Induction - single
Zone 5 - Type
Induction - single
Zone 1 - Dimensions
18.0 cm
Zone 2 - Dimensions
18.0 cm
Zone 3 - Dimensions
30.0 cm
Zone 4 - Dimensions
18.0 cm
Zone 5 - Dimensions
18.0 cm
Zone 1 - Power
1.85 kW
Zone 2 - Power
1.85 kW
Zone 3 - Power
2.80 kW
Zone 4 - Power
1.85 kW
Zone 5 - Power
1.85 kW
Zone 1 - Booster power
2.50 kW
Zone 2 - Booster power
2.50 kW
Zone 3 - Booster power
5.40 kW
Zone 4 - Booster power
2.50 kW
Zone 5 - Booster power
2.50 kW
Zone 1 - Position
Front-left
Zone 2 - Position
Rear-left
Zone 3 - Position
Center
Zone 4 - Position
Rear-right
Zone 5 - Position
Front-right
Automatic pan diameter adjustment
Yes
Automatic pot detection
Yes
Minimum pan diameter indication
Yes
Automatic switch-off in case of over-heating
Yes
Automatic switch-off in case of overflow
Yes
Residual heat indicator
Yes
Protection from accidental start
Yes
Nominal power
11100 W
Current
46 A
Voltage
120/208 V
Voltage 2 (V)
120/240 V
Frequency
60 Hz
Dimensions
84x920x541
Depth
21 5/16 "
Width
36 1/4 "
Height
3 5/16 "
Net weight
44 lbs
Gross weight
53 lbs
Packaged width
39 3/16 "
Packaged depth
23 1/4 "
Packaged height
5 1/2 "
Packaged dimensions
140X995X590
Maximum stackability
10
Packaging
Shrink-wrapped
Packaging composition - Paper
2 lbs
Packaging composition - Polystyrene
2 lbs
Packaging composition - Wood
1 lbs
GTIN
08017709207281
EAN
8017709207281
Product family: Cooktop
Aesthetics: Universal
Type: Induction
Installation: Ultra-low profile
Cooking zones
5
Cooking zones with Booster
5
No. of Flexible zones
2
Main on/off switch
Yes
Power levels
9
Product family
Cooktop
Dimensions
36"
Type
Induction
Installation
Ultra-low profile
Power supply
Electric
EAN code
8017709207281
