PRODUCT DESCRIPTION
TECHNICAL SPECIFICATIONS
Operating mode: vented or recirculating
Control knobs
4 speed levels
Maximum extraction power: 600 CFM
4 LED lights
Noise level at maximum speed: 69 dB(A)
Motor power: 455 W
4 stainless steel grease filters
ELECTRICAL SPECIFICATIONS
Nominal power: 535 W
Voltage: 120 V
Frequency: 60 Hz
Specifications
Product family
Hood
Hood Type
Decorative wall hood
Hood width
48 "
Extraction
Vented
EAN code
8017709261733
Color
Red
Aesthetics
Portofino
Design
Chimney
Material
Stainless steel
Stainless steel type
Brushed
Speed levels
4
Control setting
Control knobs
Control knobs
Portofino
No. of controls
2
Controls color
Stainless steel effect
No. of lights
4
Lighting
LED
Light power
20 W
Light color temperature scale ((degree)K)
4000 (degree)K
Maximum extraction capacity at free mode
577.5 CFM
Motor power
455 W
No. of filters
4
Anti-grease filters
Stainless steel
Minimum distance from gas cooktop
750 "
Minimum distance from electric cooktop
650 "
Vent outlet
5 7/8 "
Non-return valve
Yes
Electrical connection rating
535 W
Voltage
120 V
Frequency (Hz)
60 Hz
Power supply cable length
1000 "
Extraction rate
210.5 CFM
Noise level
53 dBA
Power
207 W
Extraction rate
317 CFM
Noise level
62 dBA
Power
270 W
Extraction rate
437.5 CFM
Noise level
69 dBA
Power
350 W
Extraction rate
573.5 CFM
Noise level
75 dBA
Power
479 W
Width
47 "
Depth
19 7/8 "
Height
46 7/8 "
Net weight
45 lbs
Gross weight
63 lbs
Packaged width
50 1/16 "
Packaged depth
20 1/4 "
Packaged height
26 3/4 "
Packaged dimensions
680X1270X515
Maximum stackability
5
Packaging
Cardboard box
Packaging composition - Paper
10 lbs
Packaging composition - Polystyrene
2 lbs
Packaging composition - Wood
1 lbs
GTIN
08017709261733
EAN
8017709261733
Product family: Hood
Hood Type: Decorative wall hood
Aesthetics: Portofino
Color: Red
Speed levels
4
Product family
Hood
Hood Type
Decorative wall hood
Extraction
Vented
EAN code
8017709261733
