PRODUCT DESCRIPTION
Features
Continuous grates
Designed for even cooking and simple movement of cookware across the surface
High-output cooking
Delivered by a 20,000 BTU tri-ring burner, total of 62,000 BTUs
Tri-ring burner
Versatile burner creates 20,000 BTUs of intense heat, perfect for searing, frying and saut(eback)ing
Dual-flame stacked burners
Provide complete 140F simmer-to-rapid-boil flexibility on all burners; the burners are sealed to the cooktop for easy cleaning
Precision knobs
With embedded sapphire glass illuminate each knob making it easy to view and select heat settings
Heavy-duty, cast-iron griddle
Designed to fit the Monogram gas cooktop
Electronic ignition
Ensures a continuous flame and reignites automatically if accidentally extinguished
Specifications
Color Appearance
Stainless Steel
Installation
Over Advantium Built-In 120V Over Single Wall Oven (except Single-Double) Over Warming Drawer
Control Knobs
Precision Knobs with Embedded Sapphire Glass
Collection
Parts Warranty
Limited 2-year entire appliance
Warranty Notes
See written warranty for full details
Labor Warranty
Limited 2-year entire appliance
Electrical Requirements
120V; 60Hz; 5.0A
Hertz
60
Conversion Kit
Included - Nat. Gas to LP
Cooktop Cleaning
Included
Overall Height
7.875 in
Cutout Depth (in)
19-1/8
Cabinet Width
36 in
Approximate Shipping Weight
65 lb
Overall Width
36 in
Net Weight
59 lb
Cutout Width (in)
33-7/8
Overall Depth
21 in
Cooktop Burner Type
5 Sealed
Valves (Degree of Turn)
270
Burner - Right Rear
10,000 BTU Dual
Burner - Right Front
12,000 BTU Dual
Fuel Type
Natural Gas
Control Location
Front Center
Cooktop Type
Continuous Grates
Ignition System
Direct Electronic Ignition
Burner - Center
20,000 BTU Tri-ring (Brass Cap)
Cooktop Surface
Stainless Steel
Burner - Left Rear
10,000 BTU Dual
Extra Low Simmer
5
Burner Indicator Light
Yes - in Knob
Automatic Re-Ignition
Yes
Cooktop Burner Grate Material
Cast-Iron; Porcelainized
Collection
Minimalist Statement
Cooktop Burner Grate Features
Continuous Grates
Griddle
JXGRIDL236 (Included)
140 Deg. Simmer Burner
5
Configuration
5 Sealed Cooktop Burners
Burner - Left Front
10,000 BTU Dual
Product Type
Cooktop
Dual Flame Stacked Burners
5
Precision knobs
Dual-flame stacked burners
High-output cooking
Tri-ring burner
Continuous grates
Electronic ignition
Heavy-duty, cast-iron griddle
GTIN
00084691822516
EAN
0084691822516
UPC
084691822516
Overall Height
7.875 in
Cutout Depth (in)
19-1/8
Cabinet Width
36 in
Approximate Shipping Weight
65 lb
Overall Width
36 in
Net Weight
59 lb
Cutout Width (in)
33-7/8
Overall Depth
21 in
