PRODUCT DESCRIPTION
Specifications
Door Panel Color
3/4" Custom Panel Required
Handle
Custom Handle Required
Panel Capability
Integrated
Installation
True Flush
Door Style
Long Door with Top Controls
Door Appearance
Fully integrated door for custom panels
Color Appearance
Custom Panel and Handle Required
Design Style
Integrated Custom Panel
Power Connection
Factory installed - w/offset flat plug, optional hardwire kit WD21X23559
Hertz
60
Electrical Requirements
120 V; 60 Hz; 10.2 A
Watts
1296
Calrod Heater Watts
1200
Energy Consumption (kWh/year)
240
Labor Warranty
Limited 2-year entire appliance
Warranty Notes
Limited 5-year rack and electronic control Ltd Lifetime SS tub and inner door
Parts Warranty
Limited 2-year entire appliance
Door Insulation
Mastic
Quiet Package
38 dBA
Outer Wrap
Bitumen + Full-wrap Blanket
Motor Type
Variable Speed
Quiet Features
38 dBA (Normal Cycle) and 37 dBA (Quiet Cycle) based on results from base model ZDT900SSYSS
Height w/ Legs Retracted - Minimum Height
33.375 in
Cutout Height (in)
33.5
Cutout Width (in)
24
Overall Depth
24 in
Cabinet Width
24 in
Net Weight
126 lb
Overall Width
23.75 in
Approximate Shipping Weight
139 lb
Overall Height
34 in
Cutout Depth (in)
24
Height w/Legs Extended - Maximum Height
34.625 in
Depth with Door Open
25.5 in
Wash System
900 Series
Sensor
Clean Sensor
Lower Rack
1 Rack handle Ball-Tip Tines Multi-Position Fold Down Tines
Tub Type
Tall Tub
Leveling System
Front Adjustable Leveling Legs
OU Certified
No
Number of Place Settings
16
Custom Panel Ready
Integrated Panels
Dishwasher Options
Bottle Wash Delay Start 1-12 Hr. Heated Dry Pre Soak Sani (Certified to NSF Standard 184) Silverware Wash Start/Reset Wash TempBoost Wash Zone Lower Only Wash Zone Upper Only
Latch
Pull with Handle
Number of Options
11
Style
Built-In Top Control
Water Filtration System
100% Filtration with Hard Food Disposer and Removable Filter
Cutlery Tray
Smooth Glide Full-Extension on Stainless Steel Ball Bearings with Wash Manifold + 1/3 Removeable for Tall Items Below
Rack Features
2 Fold-Down Tines - Lower 3 Piece Silverware Basket Adjustable Upper Rack Ball-Tipped Tines
Floor Protection
Floor Protect with Alert
Dishwasher Cycles
1 Hour Wash & Dry Auto CASCADE PLATINUM PLUS Crystal Cycles Plus Dishwasher Cleaning Favorites HydroSave Intense Normal PrepRinse Quiet
Short Description
Fully Integrated Dishwasher
Rack Color
Silver
Dispenser
Electronic Low Rinse Aid Sensor Rinse Aid with Indicator and Adjustment
WiFi Connect
Built-In
Control Type
Intuitive Touch Controls with Brilliant LCD Screen
Racking System
Adjustable 3rd rack
Dishwasher Drying Features
Max Dry System (2 Fans, 2 Heaters) with 3 Settings (Power Dry, Max Dry, Off)
Interior Lighting
LED
Wash Arms
3 Pressurized Wash Arms 90+ Spray Jet Wash System Bottle Wash Jets Jets - Variable Pressure Lower - Reversing Blade Middle - Blade Silverware Wash Jets
Wash System Features
3 Pressurized Wash Arms: Upper Nozzle, Middle Wash Arm, Variable Pressure Lower Wash Arm 90+ Water Jets with 6 Pressurized Wash Zones Automatic Temperature Control Automatic Temperature Control with Hidden Heater Bottle Wash Jets Dedicated Flatware and Utensil Wash Jets Hard Food Disposer with Removable Filter Reversing Blade Lower Wash Arm Third Rack Wash Manifold Variable Speed Dual Pumps and Motors
Connected Features
1/2 Load Wash Zones Bottle Wash Jets Cascade Platinum Plus/Shine Child Lock Dishwasher Cleaning Rinse Smart Assist II
Exterior Style
Custom Panel
Product Type
Built-In
Connected Capabilities
Amazon Alexa Amazon Dash Replenishment Google Home IFTTT Sonos The Google Assistant
Upper Rack
1 Rack handle 1/2 fixed tines, 1/2 fold down tines 2 Stem Safe Shelves Ball-Tipped Tines Premium Height Adjustable
Dishwasher Control Features
Audible End-of-Cycle Signal Hi-Resolution Color LCD Control Display Last Cycle Memory
Number of Cycles
10
Tub and Door Liner
Stainless Steel
Sabbath Mode
Yes
Showroom Power Mode
Yes
38 dBA Quiet Operation
Flush Installation Capability
HYDROSAVE(TM) Cycle
Entertainer's Third Rack With Wash Zone
Advanced Wash System
Max Dry System
Platinum Plus Cycle
LED Illuminated Interior
Steam & Sanitization
Bottle & Silverware Jets
Intuitive LCD Touch Controls
Hard Food Disposer
WiFi Connected With SmartHQ
Handles Sold Separately
Panel Ready Design
GTIN
00084691968382
EAN
0084691968382
UPC
084691968382
