Canopy dimensions (W x H x D) in mm
35 3/8 (898) x 2 3/4 (70) x 23 1/2 (598)
Overall hood height for vented mode and external in inches (mm)
27 1/8 (690)-39 (990)
Overall height for recirculation mode ventilation hoods in mm
29 1/2 (750)-41 3/4 (1060)
Overall min. height for vented and external in in. (mm)
27 1/8 (690)
Overall max. height for vented and external in in. (mm)
39 (990)
Overall min. height for recirculation in in. (mm)
29 1/2 (750)
Overall max. height for recirculation in in. (mm)
41 3/4 (1060)
Canopy width in in. (mm)
35 3/8 (898)
Canopy height in in. (mm)
2 3/4 (70)
Depth of hood canopy in in. (mm)
23 1/2 (598)
Minimum height above electric cooktops in mm
24 (610)
Minimum safety distance above gas cooktops (max. 12.6 kW total power, burner 4.5 kW) in mm
26 (660)
Net weight in lbs. (kg)
75 (34.0)
Total connected load in kW
0.362
