PRODUCT DESCRIPTION
Features
Safety functions
The safety functions protect you from any nasty surprises - even if your mind is on other things.
SmartSelect
Quick and intuitive: power levels and times can be selected separately for each cooking zone.
TwinBooster
Flexible power: Induction output can be individually distributed or used for one single zone.
Con@ctivity 3.0
Innovative convenience: The ventilation hood reacts automatically to settings on the cooktop.
Permanent pan recognition
Automatic activation of control elements: Pans already in position are recognized when the cooktop is switched on.
Convenient additional functions
Specifications
Fuel type
Induction
Independent of oven
Yes
Elegant glass ceramic surface
Yes
Ceramic surface color
Black
All-round stainless-steel frame
Yes
Proud installation
Yes
Proud/flush-mounted
-/-
No. of rings
3
Number of cooking areas
0
Maximum number of pans
3
Number of cooking zones/cooking areas
-/-
Position
left center
Type
Variable cooking zone
Size in mm
180-280
Max. rating in W
2600
Max. booster rating in W
3000
Max. TwinBooster rating in W
3700
Position
rear right
Type
Variable cooking zone
Size in mm
140-200
Max. rating in W
1850
Max. booster rating in W
2500
Max. TwinBooster rating in W
3000
Position
front right
Type
Variable cooking zone
Size in mm
100-160
Max. rating in W
1400
Max. booster rating in W
1700
Max. TwinBooster rating in W
2200
Networking with Miele@home
Yes
Automatic function
Con@ctivity 3.0
Operation via touchpad sensors
Smart Select
Display color
Yellow
Permanent pan recognition
Yes
Pan/Pan-size sensors
Yes
Stop & Go function
Yes
Wipe protection
Yes
Recall function
Yes
Minute minder
Yes
Automatic switch-off for all rings
Yes
AutoBoost
Yes
Keep-warm function
Yes
Individual setting options (e.g. acoustic signal tones)
Yes
Easy to clean ceramic glass
Yes
Safety cut-out
Yes
Lock function
Yes
System lock
Yes
Integrated cooling blower
Yes
Overheating protection
Yes
Residual heat indicator
Yes
Width in in. (mm)
24 3/4 (626)
Height in in. (mm)
3 1/8 (78)
Built-in height with mains connection box in in. (mm)
2 7/8 (71)
Depth in in. (mm)
21 1/2 (544)
Cutout dimensions width in in. (mm) with proud-mounted installation
22 3/8 in (567 mm)
Cutout dimensions depth in in. (mm) with proud-mounted installation
20 1/2 in (518 mm)
Weight in lbs. (kg)
30 (14)
Total connected load in kW
6.600-7.600
Voltage in V
208-240
Frequency in Hz
50-60
Power cord length in ft. (m)
3 (1.2)
Dimensions (H x W x D) in inches (mm)
3 1/8 (78) x 24 3/4 (626) x 21 1/2 (544)
Cut-out dimensions (W x D) with surface-mounted installation in inches (mm)
22 3/8 in (567 mm) x 20 1/2 in (518 mm)
Dimensions (H x W x D) in mm
3 1/8 (78) x 24 3/4 (626) x 21 1/2 (544)
Connection wire
•
GTIN
04002516611547
EAN
4002516611547
EAN
4002516611547
Intuitive quick selection via number sequences - Smart Select
Versatile - 3 cooking zones, 1 extra large with diameter of 11 in
With a width of 24 3/4 (626) in (mm) and stainless steel frame for proud-mounting
Shortest heating-up times - TwinBooster
Communication with the ventilation hood - automatic Con@ctivity function
Safety information
Safety functions
SmartSelect
Con@ctivity 3.0
Convenient additional functions
TwinBooster
Permanent pan recognition
