PRODUCT DESCRIPTION
Features
filter saturation indicator
Easy filter replacement: a red light lets you know when the grease and/or charcoal filter is saturated.
Delayed shutdown
Con@ctivity
Innovative convenience: the ventilation hood reacts automatically to settings on the cooktop.
Miele CleanCover
Protection and easy cleaning: The sealed, smooth surface prevents contact with cables and the motor.
Economy-Motor
Powerful and economical: The DC motor saves up to 50% electricity compared with conventional motors.
Stainless-steel grease filters (10-layer)
Looks great and does a good job: Effective grease filtering and easy cleaning inside the dishwasher.
Safety turn off
Sensible, even in case of operating errors: The ventilation hood switches off automatically after 10 hours.
Edge vented
Efficient and good-looking: With edge extraction, the grease filters are covered by a panel.
Specifications
Ceiling fan
Yes
Color
Stainless steel
Edge extraction
Yes
Recirculated mode
Can be retrofitted
OdorFree charcoal filter (order separately)
DKF 40-R
Miele@home
Yes
Automatic function Con@ctivity
Yes
Electronic controls
Yes
EasySwitch
Yes
Operation
EasySwitch
ON/OFF switch
Yes
Power levels (number excl. Intensive)
3
Booster levels
1
Programmable Intensive switch-off
Yes
Delayed shutdown for 5 or 15 minutes
Yes
Grease filter saturation indicator
Yes
Active charcoal filter saturation indicator
Yes
CleanCover
Yes
PowerManagement system
Yes
ECO motor (DC motor)
Yes
Easy-to-clean canopy interior - CleanCover
Yes
Number of dishwasher-safe stainless steel grease filters (10-ply)
4
Number x W
2 x 7,2 W
Light intensity in Lx
450 lx
Color temperature in K
3500 Kelvin
Dual-action blower
Yes
DC motor
Yes
Maximum air throughput in cfm according to HVI
356
Air throughput
Values upon request
Air throughput in CFM in Booster
356
Safety shut-off
Yes
Overall hood height for vented mode and external in inches (mm)
11 3/4 (296)
Overall height for recirculation mode ventilation hoods in mm
11 3/4 (296)
Overall min. height for vented and external in in. (mm)
11 3/4 (296)
Overall max. height for vented and external in in. (mm)
11 3/4 (296)
Overall min. height for recirculation in in. (mm)
11 3/4 (296)
Overall max. height for recirculation in in. (mm)
11 3/4 (296)
Canopy width in in. (mm)
45 7/8 (1165)
Canopy height in in. (mm)
11 3/4 (296)
Depth of hood canopy in in. (mm)
19 3/4 (500)
Minimum height above electric cooktops in mm
24 1/8 (610)
Minimum safety distance above gas cooktops (max. 12.6 kW total power, burner 4.5 kW) in mm
26 (660)
Net weight in lbs. (kg)
50 (22.3)
Length of electrical wire in ft. (m)
2 (0.7)
Standard plug fitted
Yes
Total connected load in kW
0.194
Voltage in V
120
Fuse rating in A
15
Frequency in Hz
60
Number of phases
1
Vent connection on side
Yes
Diameter of vent connection in in. (mm)
6 (150)
Non-return flap
Yes
Reducer from 150 to 125 mm
Yes
Remote control
Yes
EAN
4002516805946
Suitable for every home - vented or recirculating
Convenient operation - with Con@ctivity and remote control included
Powerful - in Booster level
Efficient filtration- 10-ply stainless steel grease filters
Panel can be customized
Safety information
filter saturation indicator
Delayed shutdown
Con@ctivity
Miele CleanCover
Economy-Motor
Stainless-steel grease filters (10-layer)
Safety turn off
Edge vented
GTIN
04002516805946
EAN
4002516805946
