PRODUCT DESCRIPTION
Features
Full-Width Cast-Iron Grates
Enhance the beautiful look of the cooktop and allow easy movement of cookware around the entire cooking surface.
Multi-Finish Back-Lit Knobs
Deliver a beautiful accent with pleasant LED lights that let you know when the burner is in use.
Removable Griddle Included
Provides a one-piece flat surface that can be used on the right, left, or center of the cooktop surface, and is ideal for making a range of dishes from crepes to quesadillas.
20,000 BTU Professional Dual Ring Burner
Allows you to go from one small flame for precise simmering to a dual flame for powerful boiling, all on the same burner.
6,000 BTU Even-Heat(TM) Simmer Burner
A diffuser plate allows more control of the flame at the lowest setting, for more precise simmering and melting.
Specifications
Ada Compliant
ADA Height and Side Reach Compliant
Prop65
Standard
Ul
Yes
Control Location
Front
Control Type
Knobs
Infinite Heat Controls
Yes
Cooktop Surface Color
Color Coordinated
Cooktop Surface Material
Stainless Steel
Digital Display
No
Griddle Included
Included
Heating Element On Indicator Light
Yes
Hot Surface Indicator Light
No
Ignition Type
Direct Spark Ignition
Number of Open Bays
N/A
Automatic Pan Detection
No
Combinations With Oven
KOES527P; KOES530P; KOSC104FSS; KOSC504; KOSE500; KOSE507; KOSE900; KOST100; KOST107
Cooktop Selections
Automatic Reignition; Simmer
Fuel Type
Gas
Installs Over Built-in Oven
Yes
Lp Convertible
Yes - Kit Included
Power Outage Compatible
Yes
Product Height
3.6875
Carton Height
12.04
Gross Weight
74
Carton Width
44.41
Product Depth
21.0
Cutout Depth Max
20
Cutout Width Min
34.875
Cutout Depth
19.813
Cutout Height
5.25
Carton Depth
25
Cutout Width
35.188
Cutout Depth Min
19.5
Cutout Width Max
35.625
Net Weight
0
Product Width
36.25
Power Cord Included
Yes
Center Rear Element-burner Power
20,000 BTU
Center Rear Element-burner Type
Professional Dual Tier
Cooktop Element Style
Sealed Burner
Cooktop Type
Standard
Left Front Element-burner Power
12,000 BTU
Left Front Element-burner Type
Burner
Left Rear Element-burner Power
6,000 BTU
Left Rear Element-burner Type
Simmer
Number of Cooking Element-burners
5
Power Boost
No
Right Front Element-burner Power
10,000 BTU
Right Front Element-burner Type
Even-Heat(TM)
Right Rear Element-burner Power
7,000 BTU
Right Rear Element-burner Type
Burner
Knob Color
Stainless Steel - Lighted Knobs
Knob Type
Metal
Combination Match With Oven
KOES527P; KOES530P; KOSC104FSS; KOSC504; KOSE500; KOSE507; KOSE900; KOST100; KOST107
Cooktop Features
20K BTU Dual-Ring Burner; ADA Compliant; Cookshield Finish; Even-Heat Melt Burner; Torch Burner
Grate Details
Cast Iron Grates; Continuous; Dishwasher Safe; Matte Finish
Number of Grates
3
Downdraft Vent
No
GTIN
00883049330402
EAN
0883049330402
UPC
883049330402
10,000 BTU EVEN-HEAT Torch Burner distributes heat aross pan
20,000 BTU Professional Dual Ring Burner for simmering or boiling
6,000 BTU EVEN-HEAT Simmer Burner for simmering and melting
CookShield Finish protects the cooktop from stains
Lights burners with an electric spark and relights them if flame goes out
Full-Width Cast-Iron Grates allow easy movement of cookware
LP Conversion Kit (not included) allows use cooktop with LP gas
Multi-Finish Back-Lit Knobs let you know when burner is in use
Removable Griddle (included) is deal for crepes amd quesadillas
Removable Griddle Included
6,000 BTU Even-Heat(TM) Simmer Burner
Full-Width Cast-Iron Grates
20,000 BTU Professional Dual Ring Burner
Multi-Finish Back-Lit Knobs
