PRODUCT DESCRIPTION
Features
V2™ Vertical Dual-Fan Convection
Dual counter-rotating vertical fans work in tandem, helping you wield your cooking prowess with everything from mouthwatering fillets to irresistible roasts.
Temperature Probe
Know when dinner is done without ever opening the door. 4 points of contact deliver temperature readings visible on the LCD screen.
Connected Temperature Probe
Know when dinner is done without ever opening the door. Readings of food’s internal temperature, visible on the LCD screen or directly from the app.
Glide Rack
Smooth moves. Glides in and out fluidly and quietly, even when fully loaded.
No Preheat Baking
Bake on a single rack without the wait.
Cinematic Lighting
Lights, camera, cook. Halogen lighting increases to full intensity, minimizing shadows and dramatically showcasing food.
Remote Access
Preheat. Check cooking status. Personalize settings. Connect to WiFi for real-time notifications and control your appliance from anywhere. Tap and swipe on both iOS and Android devices.
Versatile Cooking Modes
Uncompromising results, untroubled process. Automatically convection cook by food type, or manually select convection modes by cooking method. Take the guesswork out of convection cooking with automatic temperature and time conversions. Get even more versatile: No Preheat mode lets you bake on a single rack without the wait. Doughrises quickly and evenly with Proofing mode, and the Keep Warm™ setting lets you serve your entire menu at the same time.
5.0 Cu. Ft. Capacity
Big on entertaining. Generous capacity to cook multiple dishes at once.
Convection Tower
A touch of style in an unexpected place. Dual vertical fans work in tandem, helping you wield your cooking prowess with everything from mouthwatering fillets to irresistible roasts.
Sleek, Continuous Design
Gaps in and around the oven exterior are closed or tightened to create a clean, continuous flow with cabinetry for a seamless installation.
No Flush Kit Required for Flush Install
These wall ovens can be installed flush, creating a seamless visual line with cabinetry, without a separate accessory flush install kit.
Chef's Light
Food shown in its best light. This third halogen lamp shines above the door, front and center, further reducing shadows for clear illumination.
Up to 3,400-Watt Convection Element
This convection element wraps dishes in heat and maintains a controlled cooking environment.
Up to 2,800-Watt Hidden Bake Element
This 2,800-watt bake element is concealed beneath the oven floor, providing intense heat and a smooth surface that is easy to clean.
Up to 4,000-Watt Broil Element
Tap into high-wattage heat designed to broil meats to tantalizing caramelization.
Up to 6,800-Watt Combined Convection Cooking Power
Two convection elements combine to create powerful, intense heat for dishes that make an impact.
8-Pass Reflective Broil Element
Maximum coverage. Even heat distribution. Beneath a stainless steel broil plate, this element radiates heat back onto cookware and food.
Auto Convection Modes
Savor taste that leaves you wanting more. Choose your food type, and temperature and airflow automatically adjust for baking, broiling or roasting.
Keep Warm™ Option
Reward anticipation. Low heat keeps tempting dishes ready and waiting for the right moment.
Smooth Close Door
Quiet, soft, secure. Your oven gently pulls the door closed.
Manual Convection Modes
Select from presets like Convect Bake, Convect Roast and Convect Broil to let the cooking method guide you.
Proofing Option
Tame the temperamental. Low, consistent heat protects dough from temperature swings for an even, rapid rise.
Sabbath Mode
Select this function to bypass the oven’s automatic shutoff when observing the Sabbath and other religious holidays.
On-Demand Experts
Connect with the JennAir Epicenter through chat, email, or call to tap into the brilliant minds of experts who know JennAir® appliances inside and out. Receive diagnostic codes on the app and they'll deploy service targeted to your wall oven's best interest.
Auto Convection Conversion
Bake with abandon. The oven automatically converts temperature and cook time to make any recipe a convection recipe.
Control Lock
Control Lock prevents unintended use of the oven and ensures complete, simple cleaning of the controls.
Serviced by a Select Few
We narrowed down our dedicated network to only the most experienced providers. Armed with extensive access to products and knowledge, their expertise is unmatched.
NOIR™ Design Expression
Sculpted in stainless steel, the NOIR™ Design Expression features hidden lace textures, discoverable only by touch.
Specifications
Parts
2 Year
Labor
2 Year
Capacity(FT3,cubic feet)
10.00
Lower Oven Capacity (Cu Ft.)
5.0
Lower Oven Capacity
5
Upper Oven Capacity
5
Upper Oven Capacity (Cu Ft.)
5.0
Cubic Feet Measurement
28.19 ft³
Dimensional Weight
350.42 lbs.
Total of Cubes
28.19 ft³
Total of Dimensional Weight
350.42 lbs.
Width
30 in.
Height
52.38 in.
Length
31 in.
Weight
360 lbs.
Carton Depth
31
Carton Height
54
Carton Width
35
Gross Weight
360
Net Weight
334.0
Cutout Depth(IN,inches)
24.0000
Cutout Height(IN,inches)
52.1875
Cutout Width(IN,inches)
28.5000
Depth Closed Excluding Handles(IN,inches)
24.3125
Depth Closed Including Handles(IN,inches)
26.3750
Depth Excluding Doors(IN,inches)
23.0000
Depth With Door Open 90 Degree(IN,inches)
45.4375
Depth(IN,inches)
23.2500
Carton Depth(IN,inches)
31.0000
Carton Height(IN,inches)
54.0000
Carton Width(IN,inches)
35.0000
Cutout Depth
24
Cutout Height
52.188
Cutout Width
28.5
Depth Closed Excluding Handles
24.313
Depth Excluding Doors
23
Depth With Door Open 90 Degree
45.438
Lower Oven Interior Depth
19
Lower Oven Interior Height
18
Lower Oven Interior Width
25
Upper Oven Interior Depth
19
Upper Oven Interior Height
18
Upper Oven Interior Width
25
carton depth
31
carton height
54
carton width
35
gross weight
360
net weight
334
Number of Boxes
1
Shipping Width
35 in.
Shipping Height
54 in.
Shipping Length
36 in.
Shipping Weight
400 lbs.
Total of Shipping Weight
400 lbs.
Source
Calculation
Door Lock
Yes
Handle Color
Stainless Steel
Handle Material
Stainless Steel
Door Type
Metal & Glass
Convection Element Type
Dual Fan
Delay Clean
Yes
Flush Installation Approved
Yes
Fuel Type
Electric
LP Convertible
No
Oven Automatic Shut-Off
Yes
Oven Configuration
Double Oven
Oven Type
Double
Power On Indicator Light
Yes
Design Expression
Noir™
Oven Selections
Audible Signal, Automatic Door Latch, Bake, Broil, Cancel/off, Clock, Control Lock, Cook Time Indicator, Cook And Hold, Culinary Center, Delay Start, Favorites, Keep Warm Setting, Language Co
Convection Element Type
Dual Fan
Convection Functions
Bake Broil Roast Both
Door Broil Position
Closed
Door Lock
Yes
Hidden Bake Element
Yes
Installable Under Cooktop
No
Interior Coating
Porcelain
Interior Color
Black
Light Type
Halogen
Lower Oven Number of Oven Lights
3
Number of Bake Elements
1
Number of Broil Elements
1
Number of Lower Oven Racks
3
Number of Lower Rack Guides
6
Number of Upper Oven Racks
3
Number of Upper Rack Guides
6
Oven Cooking System
V2™ True Convection
Self-Cleaning Oven Racks
No
Upper Oven Number of Oven Lights
3
Bake Element Power
2,800 W Both
Broiler Element Power
4,000 W Both
Broiler Location
Top Of Oven
Convection Element Power
6,800 W
Lower Oven Capacity
5 Cu. Ft.
Oven Cleaning Type
Self-cleaning
Upper Oven Capacity
5 Cu. Ft.
CUL
Yes
UL
Yes
Prop 65
California Residents Only - Warning: Cancer And Reproductive Harm - Www.p65warnings.ca.gov.
ADA Compliant
Ada Height And Side And Front Reach Compliant, Ada Height And Side And Front Reach Compliant
Star K Certified
Yes, Yes
Control Type
Tap Touch
Display Color
Full Color
Light Control
Oven Light Touch Pad
Electronic Display Type
7-inch Full Color Lcd
Language Conversion
English/french
Smart Appliance
Yes
Connectivity
Amazon Alexa, Android, Google Assistant, Ios
Works With
App, Remote Access, Voice Controlled, Wifi
Amps
40
Hz
60
Power Cord Included
No
Volts
240
Watts
9
Capacity
10 Cu. Ft.
Common Size
30 In
Cutout Depth
24 In
Depth Excluding Doors
23 In
Gross Weight
360 Lbs
Lower Oven Interior Depth
19 In
Lower Oven Interior Height
18 In
Lower Oven Interior Width
25 In
Net Weight
334 Lbs
Upper Oven Interior Depth
19 In
Upper Oven Interior Height
18 In
Upper Oven Interior Width
25 In
Width
30 In
Cutout Height
52.188 In
Cutout Width
28.5 In
Depth
23.25 In
Depth Closed Excluding Handles
24.313 In
Depth With Door Open 90 Degree
45.438 In
Height
52.375 In
V2™ Vertical Dual-Fan Convection
Temperature Probe
Connected Temperature Probe
Glide Rack
No Preheat Baking
Cinematic Lighting
Remote Access
Versatile Cooking Modes
5.0 Cu. Ft. Capacity
Convection Tower
Sleek, Continuous Design
No Flush Kit Required for Flush Install
Chef's Light
Up to 3,400-Watt Convection Element
Up to 2,800-Watt Hidden Bake Element
Up to 4,000-Watt Broil Element
Up to 6,800-Watt Combined Convection Cooking Power
8-Pass Reflective Broil Element
Auto Convection Modes
Keep Warm™ Option
Smooth Close Door
Manual Convection Modes
Proofing Option
Sabbath Mode
On-Demand Experts
Auto Convection Conversion
Control Lock
Serviced by a Select Few
NOIR™ Design Expression
UPC
883049610214
