PRODUCT DESCRIPTION
Features
JX3(TM) Downdraft Ventilation System with 3 Speeds
Developed and refined by JennAir(R), this downdraft ventilation system uses proximity ventilation that helps capture smoke, steam and odors at the cooking surface, whisking them down and out for a fresh, clean kitchen. It has been designed to provide optimal cooking performance, relying on a vertically mounted, 297 CFM Motor Class blower system.
17,000 BTU Ultra-High Output Burner
Enjoy the robust heat necessary for high-powered cooking techniques, whether searing a steak, stir-frying vegetables or rapidly boiling water.
Brass Burners with Removable Base
Elegant brass burners effectively direct heat for desired cooking results and can be removed for easy cleaning.
5,000 BTU Ultra-Low Output Burner with Melt Cap
Provides the optimal temperature for gently cooking delicate sauces and foods.
Specifications
Ada Compliant
Yes
Prop65
Standard
Ul
Yes
Control Location
Right Front
Control Type
Knobs
Infinite Heat Controls
Yes
Cooktop Surface Color
Stainless
Digital Display
No
Griddle Included
N/A
Heating Element On Indicator Light
No
Hot Surface Indicator Light
No
Ignition Type
Flame-Sensing(TM) Re-ignition
Number of Open Bays
N/A
Automatic Pan Detection
No
Cooktop Selections
Convertible to Duct Free Ventilation; Melt Cap
Design Expression
Stainless Steel
Fuel Type
Gas
Installs Over Built-in Oven
No
Lp Convertible
Yes - Kit Included
Number of Vent Speeds
3
Power Outage Compatible
Yes
Product Height
4.0
Cutout Depth
19.938
Carton Height
23.78
Gross Weight
93.6
Carton Depth
26.38
Carton Width
41.5
Cutout Width
34.75
Product Depth
21.5
Net Weight
80.6
Product Width
36.0
Power Cord Included
Yes
Center Front Element-burner Power
15,000 BTU
Center Front Element-burner Type
Sealed Burner
Center Rear Element-burner Power
12,500 BTU
Center Rear Element-burner Type
Sealed Burner
Cooktop Element Style
Sealed Burner
Cooktop Type
Downdraft
Left Front Element-burner Power
10000 BTU
Left Front Element-burner Type
Sealed Burner
Left Rear Element-burner Power
5,000 BTU
Left Rear Element-burner Type
Even-Heat(TM)
Number of Cooking Element-burners
5
Power Boost
No
Right Rear Element-burner Power
17,000 BTU
Right Rear Element-burner Type
Sealed Burner
Knob Color
Stainless Steel
Knob Type
Metal
Grate Details
Cast Iron Grates; Continuous; Dishwasher Safe; Matte Finish
Number of Grates
4
Cfm Motor Class
310
Downdraft Vent
Yes
Ventilation Type
Downdraft
GTIN
00883049414416
EAN
0883049414416
UPC
883049414416
Helps capture smoke, steam and odors at the cooking surface.
JX3(TM) Downdraft Ventilation System with 3 Speeds
5,000 BTU Ultra-Low Output Burner with Melt Cap
Brass Burners with Removable Base
17,000 BTU Ultra-High Output Burner
