PRODUCT DESCRIPTION
Specifications
Ada Compliant
ADA Height and Operation Compliant
Prop65
Standard
Ul
Yes
Control Location
Front
Control Type
Knobs
Infinite Heat Controls
Yes
Cooktop Surface Color
Stainless
Cooktop Surface Material
Stainless Steel
Digital Display
No
Griddle Included
N/A
Heating Element On Indicator Light
No
Hot Surface Indicator Light
No
Ignition Type
Flame-Sensing(TM) Re-ignition
Number of Open Bays
N/A
Automatic Pan Detection
No
Automatic Pan Size Adjustment
No
Combinations With Oven
JJW2424; JJW2427; JJW2430; JJW3430; JJW6024
Cooktop Configuration
All Burners
Fuel Type
Gas
Installs Over Built-in Oven
Yes
Lp Convertible
Yes - Kit Included
Power Outage Compatible
Yes
Product Height
5.1875
Carton Height
8.25
Gross Weight
41
Carton Width
23.63
Product Depth
20.0625
Cutout Depth Max
19.375
Cutout Width Min
23.5
Cutout Height
3.333
Carton Depth
28.38
Cutout Depth Min
19.313
Cutout Width Max
23.625
Net Weight
37.4
Product Width
24.5
208v Compatible
No
Power Cord Included
Yes
Cooktop Element Style
Sealed Burners
Cooktop Type
Standard
Left Front Element-burner Power
18,000 BTU
Left Front Element-burner Size
4.5in.
Left Front Element-burner Type
Dual
Left Rear Element-burner Power
6,300 BTU
Left Rear Element-burner Size
3in.
Left Rear Element-burner Type
Standard
Number of Cooking Element-burners
4
Power Boost
No
Right Front Element-burner Power
4,000 BTU
Right Front Element-burner Size
2in.
Right Front Element-burner Type
Standard
Right Rear Element-burner Power
12,000 BTU
Right Rear Element-burner Size
4in.
Right Rear Element-burner Type
Standard
Knob Color
Stainless Steel
Knob Type
Metal
Combination Match With Oven
JJW2424; JJW2427; JJW2430; JJW3430; JJW6024
Grate Details
Cast Iron Grates; Individual
Number of Grates
4
Downdraft Vent
No
Ventilation Type
Updraft
GTIN
00883049662220
EAN
0883049662220
UPC
883049662220
Up to 12,000 BTU output for high temperature cooking
Reaches a maximum of 18,000 BTUs and a low of 450 BTUs
Up to 4,000 BTU output for versatile cooking needs
Up to 6,300 BTU output for everyday cooking functions
Designed to meet ADA standards
Ability to install over a single built-in wall oven
Precisely control heating levels with Die-Cast Metal Knobs
Flame-Sensing(TM) Reignition sparks the flame back to life
Select preferred burner settings for precise temperature control
A sleek cooktop surface designed with brushed stainless steel
Prevents liquid spills and foods from falling into the burner
A dedicated network of experienced service providers
