PRODUCT DESCRIPTION
Specifications
Parts
2 Year
Labor
2 Year
Freezer Volume (Cu Ft)
6.42
Refrigerator Volume (Cu Ft)
17.75
Total Volume (Cu Ft)
24.2
Capacity(FT3,cubic feet)
24.17
Depth Closed Excluding Handles(IN,inches)
24.7500
Depth Excluding Doors(IN,inches)
24.0000
Depth With Door Open 90 Degree(IN,inches)
44.0000
Refrigerator Capacity Volume
16-7/10
Cabinet Width
41 In
Capacity
24.2 Cu. Ft.
Common Size
42 In
Cutout Depth
25-3/4 In
Cutout Height
83-1/4 In
Cutout Width
42 In
Depth
24 In
Depth Closed Excluding Handles
24-3/4 In
Depth Closed Including Handles
27-3/8 In
Depth Excluding Doors
23-1/2 In
Depth With Door Open 90 Degree
43-3/4 In
Freezer Capacity Volume
5.9 Cu. Ft.
Gross Weight
595 Lbs
Height
84 In
Height To Top Of Cabinet
83-1/8 In
Net Weight
570 Lbs
Total Refrigerator Capacity Volume
24.2 Cu. Ft.
Width
41-3/4 In
Width Doors Open 90 Degrees
43-3/4 In
Refrigerator Type
French Door
Counter Depth
Yes
Refrigeration Configuration
Refrigerator
Design Expression
Panel-ready
Installation Configuration
Built-in
Refrigerator Type
Built-in French Door
Number of Doors
3
Automatic Defrost
Yes
Control Location
Interior Up Front
Control Type
Touch Pad
Door Ajar/Open Alarm
Yes
Max Cool/Fast Cool
Yes
Cooling Type
Dual Evaporator
LCD Touch Screen
No
Max Ice
Yes
Sabbath Mode
Sabbath Mode, Yes
Number of Interior Shelves
4
Door Bins
2 Fixed Full-Width Gallon, 4 Adjustable Full-Width
Freezer Drawer/Basket
1 Full Width Lower Plastic, 2 Half Width Upper Plastic
Icemaker
Factory Installed
ADA Compliant
No
Energy Star® Certified
No
UL
Yes
CEE Tier Rating
Not Rated
Energy Star® Qualified
No
Prop 65
California Residents Only - Warning: Cancer And Reproductive Harm - Www.p65warnings.ca.gov.
Amps
20
Hz
60
Volts
115
Capacity (Cu Ft)
24.17
Depth Closed Excluding Handles
24 3/4
Depth Excluding Doors
24
Depth With Door Open 90 Degree
44
Capacity (Cu Ft)
24.17
Dispenser Type
No Dispenser
Freezer Capacity Volume
5.9
Refrigerator Capacity Volume
16.7
Total Refrigerator Capacity Volume
24.2
Capacity(FT3,cubic feet)
24.17
Cubic Feet Measurement
69.76 ft³
Dimensional Weight
867.27 lbs.
Total of Cubes
69.76 ft³
Total of Dimensional Weight
867.27 lbs.
Cabinet Finish
Smooth
Counter Depth
Yes
Door Style
Flat
Hidden Hinge
Yes
Reversible Door
No
Door Color
Panel Ready
Air Filter Indicator/Reset
No
Fresh Flow Air Filter Included
No
Produce Preserver
No
Water Filter Indicator/Reset
No
Water Filter Location
Exterior
Water Filter Part Number
Edr3rxd1
Freezer Door Bins
No
Freezer Lighting
Incandescent
Freezer Number of Shelves
0
Freezer Shelves
None
Freezer Drawer/Basket
1 Full Width Lower Plastic, 1 Half Width Upper Plastic
Freezer Door Type
Pull-out
Icemaker
Factory Installed
Icemaker Location
Freezer
Types of Ice
No
Conventional Shelves
No
Deli Drawer
No
Humidity-Controlled Crispers
None
Liner Finish
Obsidian
Non Climate Control Drawers
2 Half Width
Number of Interior Shelves
5
Pantry Drawer
No
Supplementary Containers
Wine Rack
Temperature-Controlled Drawers
2 Half Width
Spill-Proof Glass Shelves
1 Fixed Full Width, 4 Adjustable Half Width
Refrigerator Door Bins
2 Dairy, 2 Fixed Gallon, 4 Adjustable Full-width
Refrigerator Lighting
Multi-point Lighting, Incandescent
Width
44.5 in.
Height
86 in.
Length
31.5 in.
Weight
595 lbs.
Cabinet Width (in)
41
Carton Depth
31 1/2
Carton Height
86
Carton Width
44 1/2
Cutout Depth (in)
25
Cutout Height (in)
84
Cutout Width (in)
42
Depth Closed Excluding Handles
24.75
Depth Excluding Doors
23.5
Depth With Door Open 90 Degree
43.75
Gross Weight
595
Net Weight
570.0
Cabinet Width (IN,inches)
41.0000
Cutout Depth(IN,inches)
25.0000
Cutout Height(IN,inches)
84.0000
Cutout Width(IN,inches)
42.0000
Depth Closed Excluding Handles(IN,inches)
24.7500
Depth Excluding Doors(IN,inches)
24.0000
Depth With Door Open 90 Degree(IN,inches)
44.0000
Depth(IN,inches)
24.0000
Net Weight(LB,pounds)
570
Carton Depth(IN,inches)
31.5000
Carton Height(IN,inches)
86.0000
Carton Width(IN,inches)
44.5000
Cutout Height Min(IN,inches)
84.0000
Gross Weight(LB,pounds)
595
Cabinet Width
41
Cutout Depth
25.75
Cutout Height
83.25
Cutout Width
42
Depth Closed Including Handles
27.375
Height To Top Of Cabinet
83.125
Width Doors Open 90 Degrees
43.75
carton depth
31.5
carton height
86
carton width
44.5
gross weight
595
net weight
570
Number of Boxes
1
Shipping Width
44.5 in.
Shipping Height
86 in.
Shipping Length
36.5 in.
Shipping Weight
635 lbs.
Total of Shipping Weight
635 lbs.
Source
Calculation
Dispenser Type
No Dispenser
Daring Obsidian Interior
FreshFlow Air Filter
Automatic Ice Maker
Max Ice option
TwinFresh Climate Control System
Multi-Point Cinematic Lighting
Fully Flush, Fully Integrated Design
Precision Temperature Management System
Glass Shelving
Light-Guided Capacitive Touch Controls
Capacitive Touch Controls with LED Display
Precision Temperature Management™ System
UPC
883049336930
GTIN
00883049336930
EAN
0883049336930
Ada Compliant
No
Cee Tier Rating
Not Rated
Energy Rating (kwh/year)
579
Prop65
CA
Ul
Yes
Automatic Defrost
Yes
Control Location
Interior Up Front
Control Type
Touch Pad
Cooling Type
Dual Evaporator
Door Ajar/open Alarm
Yes
LCD Touch Screen
No
Max Cool/fast Cool
Yes
Max Ice
Yes
Sabbath Mode
Sabbath Mode
Installation Configuration
Built-In
Refrigeration Configuration
Refrigerator
Refrigerator Type
Built-In French Door
Product Height
84.0
Carton Height
86
Gross Weight
595
Height To Top of Cabinet
83.125
Carton Width
44.5
Total Refrigerator Capacity Volume
24.2
Product Depth
24.0
Depth With Door Open 90 Degree
43.75
Depth Excluding Doors
23.5
Cabinet Width
41
Cutout Depth
25.75
Cutout Height
83.25
Depth Closed Excluding Handles
24.75
Depth Closed Including Handles
27.375
Dispenser Type
No Dispenser
Carton Depth
31.5
Cutout Width
42
Freezer Capacity Volume
5.9
Refrigerator Capacity Volume
16.7
Net Weight
570
Product Width
41.75
Width Doors Open 90 Degrees
43.75
Cabinet Finish
Smooth
Counter Depth
Yes
Door Style
Flat
Hidden Hinge
Yes
Reversible Door
No
Air Filter Indicator/reset
No
Fresh Flow Air Filter Included
No
Produce Preserver
No
Water Filter Indicator/reset
No
Water Filter Location
Exterior
Water Filter Part Number
EDR3RXD1
Freezer Door Bins
No
Freezer Door Type
Pull-Out
Freezer Drawer/basket
1 Full Width Lower Plastic; 1 Half Width Upper Plastic
Freezer Lighting
Incandescent
Freezer Number of Shelves
0
Freezer Shelves
None
Energy Star(r) Qualified
No
Icemaker
Factory Installed
Icemaker Location
Freezer
Types of Ice
No
Conventional Shelves
No
Deli Drawer
No
Humidity-controlled Crispers
None
Liner Finish
Obsidian
Non Climate Control Drawers
2 Half Width
Number of Interior Shelves
5
Pantry Drawer
No
Refrigerator Door Bins
2 Dairy; 2 Fixed Gallon; 4 Adjustable Full-Width
Refrigerator Lighting
Multi-Point Lighting
Spill-proof Glass Shelves
1 Fixed Full Width; 4 Adjustable Half Width
Supplementary Containers
Wine Rack
Temperature-controlled Drawers
2 Half Width
