PRODUCT DESCRIPTION
Features
Perimetric Extraction
Provides exceptional ventiliation performance built into an attractive design by capturing cooking vapors through a thin slot and speeding the air, all while maintaining quiet operation.
Semi-Flush Installation
Subtlety that dares to be ignored. Standing semi-flush at 3mm above the countertop, this precision edge is minimalism magnified.
JX3(TM) Downdraft Ventilation System with 3 Speeds
Developed and refined by JennAir(R), this downdraft ventilation system uses proximity ventilation that helps capture smoke, steam and odors at the cooking surface, whisking them down and out for a fresh, clean kitchen. It has been designed to provide optimal cooking performance, relying on a vertically mounted, 297 CFM Motor Class blower system.
Emotive Controls
Striking and inviting controls with LED lighting unleash performance at your touch.
Specifications
Cooktop Surface Material
Ceramic Glass
Automatic Pan Detection
No
Cooktop Selections
Convertible to Duct Free Ventilation; DownDraft
Design Expression
Black Glass
Fuel Type
Electric Radiant
Installs Over Built-in Oven
No
Lp Convertible
No
Number of Vent Speeds
3
Power Outage Compatible
No
Size (in.)
30
Fuel Type
Electric Radiant
Cooktop Type
Downdraft
ADA Compliant
Yes
Energy Rating (kWh/year)
258
Prop 65
Standard
UL
Yes
Ada Compliant
Yes
Prop65
Standard
Ul
Yes
CFM Motor Class
310
Number of Vent Speeds
3
Design Expression
Black Glass
Left Front Element-Burner Type
Dual
Right Front Element-Burner Power
1200W
Left Rear Element-Burner Size
6in.
Cooktop Element Style
Radiant
Number of Cooking Element-Burners
4
Left Rear Element-Burner Type
Hyper
Right Rear Element-Burner Power
3000W/1400W
Right Rear Element-Burner Type
Dual-Stacked Burner
Right Front Element-Burner Type
Single
Left Front Element-Burner Size
10in./6in.
Right Rear Element-Burner Size
9in./6in.
Left Rear Element-Burner Power
1,300W
Cooktop Surface Color
Black
Cooktop Selections
Convertible to Duct Free Ventilation,DownDraft
Right Front Element-Burner Size
6in.
Cooktop Surface Material
Ceramic Glass
Digital Display
Yes
Griddle Included
N/A
Heating Element On Indicator Light
Yes
Hot Surface Indicator Light
Yes
Accessory Relationships
Yes
Control Location
Right Front
Control Type
Electronic Touch
Infinite Heat Controls
No
Carton Depth(IN,inches)
26.4375
Net Weight(LB,pounds)
65
Carton Width(IN,inches)
35.1250
Carton Height(IN,inches)
23 13/16
Depth(IN,inches)
22 1/16
Gross Weight(LB,pounds)
78
Width(IN,inches)
30.8750
Product Height
3.6563
Carton Height
23.78
Gross Weight
78
Carton Depth
26.38
Carton Width
35.12
Product Depth
22.0625
Net Weight
65.25
Product Width
30.875
Installs Over Built-In Oven
No
Power Boost
No
Downdraft Vent
Yes
Power Outage Compatible
No
Automatic Pan Detection
No
Digital Display
Yes
Griddle
N/A
Hot Surface Indicator Light
Yes
Heating Element On Indicator Light
Yes
LP Convertible
No
JX3(TM) Downdraft Ventilation System with 3 Speeds
Emotive Controls
Oblivion Glass Surface
Semi-Flush Installation
Hot Surface Indicators
Badasses at the Ready
Serviced by a Select Few
Optional Duct-Free Ventilation Kit
Duct-Free Filter
297 CFM Motor Class Blower
Perimetric Extraction
Two 6 Inch Elements
Radiant Elements
White LEDs unleash performance at your touch.
Helps capture smoke, steam and odors at the cooking surface.
A frameless cooktop in obsidian black glass.
Installs semi-flush, 3mm above the countertop
Volts
220
Amps
40
Power Cord Included
No
GTIN
00883049592336
EAN
0883049592336
UPC
883049592336
Cooktop Element Style
Radiant
Cooktop Type
Downdraft
Left Front Element-burner Power
3000W/1400W
Left Front Element-burner Size
10in./6in.
Left Front Element-burner Type
Dual
Left Rear Element-burner Power
1,300W
Left Rear Element-burner Size
6in.
Left Rear Element-burner Type
Hyper
Number of Cooking Element-burners
4
Power Boost
No
Right Front Element-burner Power
1200W
Right Front Element-burner Size
6in.
Right Front Element-burner Type
Single
Right Rear Element-burner Power
3000W/1400W
Right Rear Element-burner Size
9in./6in.
Right Rear Element-burner Type
Dual-Stacked Burner
Cfm Motor Class
310
Downdraft Vent
Yes
