Hestan Commercial Cheesemelters

Name: Hestan HCMW36 Commercial Cheesemelters
Brand: Hestan
SKU: HCMW36
Availability: InStock

SKU: HCMW36

0 Questions & 0 Answers

Hestan |Authorized Dealer

Special Order

PRODUCT DESCRIPTION

Hestan modular cheesemelters brown, melt or just hold your dishes with intense and consistent infrared heat - while the tilted burner design directs that heat away from the chef. The entire unit slides easily across the width of risers, so it s always right where it needs to be. A five-position ladder rack allows for optimum placement of dishes.

features

18 items

Unique wide-open chassis design for maximum visibility from all directions

Heavy-duty gas-powered infrared burner up to 30,000 Btu/hour, with intense and efficient infrared heat

Heavy-duty inconel burner screens with optimum combustion efficiency, durability and flame stability

Tilted burner design for heat deflection and rear flue system to direct heat away from the user and controls

Patented durable attachment design to allow complete horizontal movement of the broiler along the length of the riser

Front-mounted on/off gas valve for optimum flame control and stability

Heavy-duty nickel-plated broiling rack and five-position ladder rack supports

Removable stainless steel drip tray for easy cleaning

Range mount (R) model with tall riser, wall-mount (W) model with mounting bracket or counter (C) model with 4" countertop legs

Heavy-gauge welded body construction

Standing pilot ignition system with front-accessible pilot adjustment

Patented Zamak die-cast knobs and bezels with set screws

Stainless steel front, sides, top and bottom

3/4" manifold and rear gas supply connection

Optional Features

Patented customizable Marquise Accented TM valve panel (contact sales department for available options)

Two removable side shields; units may be mounted adjacent to one another with 0" side clearance

Additional broiling rack

Documents

Specs

PDF

Owner s Guide (pdf)

PDF

Hestan Warranty(PDF)

PDF

Hestan Spec Book(PDF)

PDF

Cleaning Instruction Manual(PDF)

PDF

Cheesemelter HCMS36 Service Parts List

PDF

Cheesemelter HCMD36 Service Parts List

PDF

Cheesemelter HCMS 48, 54, 60, 72 Service Parts

PDF

Cheesemelter 24, 30, 36 C,R,W Service Parts List

PDF

Cheesemelter HCMD 48, 54, 60, 72 Service Parts List

PDF

Cheesemelter 48, 54, 60, 72 C,R,W Service Parts List

PDF
